2018 Microchip Technology Inc. DS20006081A-page 1
MIC2874
Features
• Up to 1.2A Flash LED Driving Current
• Highly Efficient Synchronous Boost Driver
• Control through Single-Wire Serial Interface or
External Control Pin
• Input Voltage Range: 2.7V to 5.5V
• True Load Disconnect
• Configurable Safety Time-Out Protection
• Output Overvoltage Protection (OVP)
• LED Short Detection and Protection
• 1 µA Shutdown Current
• Available in 9-Bump 1.30 mm x 1.30 mm WLCSP
Package
Applications
• Camera Phones/Mobile Handsets
• Cell Phones/Smartphones
• LED Light for Image Capture/Auto-Focus/
White Balance
• Handset Video Light (Torch Light)
• Digital Cameras
• Portable Applications
General Description
The MIC2874 is a high-current, high-efficiency Flash
LED driver. The LED driver current is generated by an
integrated inductive boost converter with a 4 MHz switch-
ing frequency, which allows for the use of a very small
inductor and output capacitor. These features make the
MIC2874 an ideal solution for high-resolution camera
phone LED Flash light driver applications.
MIC2874 operates in either Flash or Torch mode that can
be controlled through the single-wire serial interface
and/or external control pin. A robust single-wire serial
interface allows the host processor to control the LED
current and brightness. The MIC2874 is available in a
9-bump 1.30 mm x 1.30 mm WLCSP package.
1.2A High-Brightness Flash LED Driver with
Single-Wire Serial Interface
