MIC95410 Evaluation Board
6.6mΩ R
DS(ON)
, 7A, 5.5V
IN
Load Switch in
1.2 ackagemm x 2.0mm QFN P
General Description
The MIC95410 is a high side load switch- used for
computing and dense embedded computing -for ultra
boards where high- , -current low voltage rails from sub-1V
to 5.5V have to be sectioned. The integrated 6.6mΩ
RDS(ON) N-channel MOSFET ensures low voltage drop and
low power dissipation while delivering up to 7A of load
current.
The MIC95410 provides user-adjustable slew- -rate
controlled turn-on to limit the inrush current to the input
supply voltage.
The MIC95410 is available in thermally efficient, space -
saving 10- × pin 1.2mm 2.0mm QFN package with 0.5mm
pin pitch and an operating junction temperature range from
– 40°C to +125°C.
The basic parameters of the MIC95410 evaluation board
are the IN supply of 1V to 5.5 separated bias V and the
voltage from 2.7V to 9V. It also includes a TTL-logic level
turn- on command (CTL) and an output discharge function
when disabled.
Due to the mized pinout of the MIC95410opti , the
evaluation board can achieve only routing (top a two- -layer
and bottom), while internal planes are connected to GND
and kept as solid GND planes for best thermal
performance. See section.PCB Layout
MIC95410 datasheet and support documentation are
available on Micrel’s web site at: www.micrel.com.
Ordering Information
Part Number Description
MIC95410YFL EV MIC95410 Evaluation Board
Evaluation Board
Micrel Inc. • 2180 Fortune Drive • San Jose, CA 95131 • USA • tel +1 (408) 944-0800 • fax + 1 (408) 474-1000 • http://www.micrel.com
October 1, 2014
Revision 1.0
