GENERAL DESCRIPTION
■SY89826L 1:22 LVDS fanout buer
■Single +3.3V power supply
■AC-coupled conguration for ease-of-use
■I/O interface includes onboard termination
■Fully assembled and tested
■Can be recongured for DC-coupled operation
FEATURES
3.3V PRECISION 1:22 LVDS
FANOUT BUFFER/TRANSLATOR
WITH 2:1 INPUT MUX
Precision Edge™
SY89826L
Evaluation Board
Rev.: A Amendment: /0
Issue Date: July 2004
The SY89826L evaluation board is designed for
convenient setup and quick evaluation of the SY89826L. It
allows the user to evaluate the part over its full voltage-
range without requiring any modications to the board.
The evaluation board standard configuration is AC-
coupled for direct interface to a 50 compatible oscilloscopeΩ
without split supplies. For applications that require a DC-
coupled configuration, step-by-step instructions for modifying
the board are included.
The board is fully assembled and tested.
All data sheets and support documentation can be found
on Micrel’s web site at www.micrel.com.
EVALUATION BOARD
Precision Edge is a trademark of Micrel, Inc.
AC-Coupled Evaluation Board
Part Number Function Data Sheet Link
SY89826L 3.3V, 1GHz Precision 1:22 LVDS Fanout Buer/Translator www.micrel.com/product-info/products/sy89826l.shtml
with 2:1 Input MUX Data Sheet
RELATED PRODUCT AND SUPPORT DOCUMENTATION
