CSS326-24G-2S+RM
CSS326-24G-2S+RM
The CSS is a switch with 24 Gigabit Ethernet ports and two SFP+ ports. All ports are connected through a switch chip. The device runs SwOS operating
system, specifically made for Switches.
Safety Warnings
Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The Installation of the equipment must comply with local and national electrical codes.
This unit is intended to be installed in the rackmount. Please read the mounting instructions carefully before beginning installation. Failure to use the
correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
This product is intended to be installed indoors. Keep this product away from water, fire, humidity or hot environments.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
Read the installation instructions before connecting the system to the power source.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your
own risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power plug from the power outlet.
It is the customer's responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All Mikrotik devices must be professionally installed.
Quick start
Install the device into the rackmount (see " ").Mounting
Connect your managed devices.
Connect the power source.
In your computer, set the IP address to static: 192.168.88.2/24
Open your web browser and enter the IP address of your Switch (192.168.88.1 by default) and the login screen will appear.https://wiki.mikrotik.
com/wiki/SwOS/CSS326#Connecting_to_the_Switch
User name admin and no password, (or, for some models, check user and wireless passwords on the sticker)
We recommend clicking the "Check for updates" button and updating your software to the latest version to ensure the best performance and
stability.
Set up your password to secure the device.
Powering
The device accepts power from the power jack or from the first Ethernet port (Passive PoE).
Direct-input power jack (5.5mm outside and 2mm inside, female, pin positive plug) accepts 11-30V DC.
The first Ethernet port accepts passive PoE input 11-30V DC.
Power consumption 19 W.
Connecting to a PoE Adapter:
Connect the Ethernet cable from the device to the PoE+DATA port of the PoE adapter.
Connect an Ethernet cable from your local network (LAN) to the PoE adapter.
Probleemoplossing Mikrotik CSS326-24G-2S+RM
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Wit |
| Breedte: | 440 mm |
| Diepte: | 144 mm |
| Hoogte: | 44 mm |
| Gebruikershandleiding: | Ja |
| Vormfactor: | 1U |
| Inclusief AC-adapter: | Ja |
| Intern geheugen: | 2 MB |
| Type processor: | Ja |
| Netwerkstandaard: | IEEE 802.1Q |
| Ondersteunde beveiligingsalgoritmen: | SNMP |
| Web-gebaseerd management: | Ja |
| Reset button: | Ja |
| Rack-montage: | Ja |
| MAC adres filtering: | Ja |
| Aantal voedingen: | 1 |
| Flash memory: | 2 MB |
| Vermogenstoevoer inclusief: | Ja |
| VLAN=ondersteuning: | Ja |
| Access Control List (ACL): | Ja |
| Power over Ethernet (PoE): | Ja |
| Switchingcapaciteit: | - Gbit/s |
| MAC-adrestabel: | - entries |
| 10G support: | Ja |
| Aantal VLANs: | 4000 |
| Switch type: | Managed |
| Aantal basis-switching RJ-45 Ethernet-poorten: | 24 |
| Netstekker: | DC-in ingang |
| Montagebeugels meegeleverd: | Ja |
| Type basis-switching RJ-45 Ethernet-poorten: | Gigabit Ethernet (10/100/1000) |
| Port mirroring: | Ja |
| Spanning tree protocol: | Ja |
| Stroomverbruik (typisch): | 19 W |
| Bedrijfstemperatuur (T-T): | -40 - 70 °C |
| Code geharmoniseerd systeem (HS): | 85176990 |
| Aantal moduleslots SPF+: | 2 |
| Broadcast stormbeheer: | Ja |
