Intercell
Intercell 10 B38+B39
The intercell 10 B38+B39 is an outdoor TDD-LTE dual carriers base station with 2*(2*10W) output power (each carrier supports 2x2 MIMO with 10W
output for each RF channel).
Quickstart
Please follow these quick steps to set up your device:
Connect external antennas and Ethernet cable to the connectors (see " ");Expansion ports and slots
Connect the device to the power source (see " ");Powering
Connect your laptop to the Ethernet port for configuration.
The device can get the IP address by DHCP and Static assignment;
Once connected, default maintenance IP address: 192.168.200.200, user name: admin, password: MikroTik;
If connecting with the Static assignment method, configure the IP address of your laptop as 192.168.200.100/24, then connect through HTTPS to
the device: 192.168.200.200;
Configure backhaul and radio network see " ".Configuration
Powering
The device accepts power in the following way:
The input power jack accepts 48 V DC. The only connector with cable is provided with the package, you will need the power unit - generating 48
V.
The power consumption under maximum load can reach 200 W.
Connect provided cable to your power source.
Connect the cable connector to the device.
If using an Ethernet cable add RBGESP to the setup, which comes with the package.
Configuration
All configuration is necessary to carry out through the webGUI.
The configuration of this device should be done by a qualified person.
