Pagina 1/21
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick Guide
EN - English -Quick GuideEN - English -Quick Guide:
This Quick Guide covers the model: RB5009UPr+S+OUT.
This is a Network Device. You can find the product model name on the case label (ID).
Please visit the user manual page on for the full up-to-date user manual. Or scan the QR code with your mobile phone.https://mt.lv/um
The most relevant technical specifications for this product can be found on the last page of this Quick Guide.
Technical specifications, Full EU Declaration of Conformity, brochures, and more info about products at https://mikrotik.com/products
Configuration manual for software in your language with additional information can be found athttps://mt.lv/help
MikroTik devices are for professional use. If you do not have qualifications please seek a consultanthttps://mikrotik.com/consultants
First steps:
First steps:
First steps:
First steps:First steps:
Make sure your ISP is allowing hardware change and will automatically issue an IP address.
Connect your ISP cable to the first Ethernet port.
Connect your PC to any of the Ethernet ports.
Connect the device to the power source.
Use a Web browser or WinBox to connect to the default IP address of 192.168.88.1 from any port, with the username and no password
admin
(or, for some
models, check user and wireless passwords on the sticker).
If IP is not available, download WinBox from our webpage and use it to connect through MAC address.
Update RouterOS software to the latest version, and make sure that the device has an internet connection.
If the device does not have an internet connection update software by downloading the latest version from our webpagehttps://mikrotik.com/download
Find the latest software and choose your packages.
To get the architecture type of your device model, open WinBox, WebFig go to (System/Resources).
Download packages to the PC and upload them to the WinBox, WebFig, (Files) menu, and reboot the device.
Set up your password to secure the device.
Safety Information:
Safety Information:
Safety Information:
Safety Information:Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only accessories approved by the manufacturer, and which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product is intended to be mounted outdoors on a pole. Please read the mounting instructions carefully before beginning installation. Failure to use the
correct hardware and configuration or to follow the correct procedures could result in a hazardous situation for people and damage to the system.
When powering the device using a DC power adapter, the length of the DC cable shall not exceed 3 meters.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate
measures.
Manufacturer: Mikrotikls SIA, Unijas 2, Riga, Latvia, LV1039.
Note:
Note:
Note:
Note:Note:For some models, check the user and wireless passwords on the sticker.
This device needs to be upgraded to v7.7 or the latest software version to ensure compliance with local authority regulations!
It is the end users' responsibility to follow local country regulation. All MikroTik devices must be professionally installed.
Probleemoplossing Mikrotik RB5009UPr+S+OUT
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Wit |
| Breedte: | 222 mm |
| Diepte: | 239 mm |
| Hoogte: | 57 mm |
| Gebruikershandleiding: | Ja |
| Frequentie van processor: | 1400 MHz |
| Processormodel: | 88F7040 |
| Interne opslagcapaciteit: | 1 GB |
| Inclusief besturingssysteem: | RouterOS |
| Type stroombron: | Power over Ethernet (PoE) |
| Aantal Ethernet LAN (RJ-45)-poorten: | 8 |
| Aantal USB-aansluitingen: | 1 |
| Certificering: | CE, EAC, ROHS |
| USB-versie: | 3.2 Gen 1 (3.1 Gen 1) |
| Aansluiting voor netstroomadapter: | Ja |
| Intern geheugen: | 1024 MB |
| Type processor: | Ja |
| SIM-kaartsleuf: | Nee |
| 3G/4G USB modem compatibiliteit: | Nee |
| Netwerkstandaard: | IEEE 802.3af, IEEE 802.3at |
| Processorfabrikant: | Marvell |
| Ethernet WAN: | Nee |
| Ethernet interface type: | 2.5 Gigabit Ethernet, Gigabit Ethernet |
| Mean time between failures (MTBF): | 200000 uur |
| Power over Ethernet (PoE): | Ja |
| DSL WAN: | Nee |
| Stroomverbruik (typisch): | 150 W |
| Bedrijfstemperatuur (T-T): | -40 - 70 °C |
| Aantal moduleslots SPF+: | 1 |
| Temperatuurbewaking: | Ja |
| Hoeveelheid Power over Ethernet (PoE) ports: | 8 |
| Spanningsbewaking: | Ja |
| SFP WAN: | Nee |
