Paper Holder
posts are die cast from
highest quality zinc alloy (zamac).
Castings are triple plated with a
polished brass, polished chrome or a
powder coated white finish. Roller is
plastic and spring loaded.
q
5808PB
–
Paper Holder
Polished Brass Finish,
Concealed Screw Mounting.
Matching Plastic Roller.
q 5808CH – Paper Holder
Polished Chrome Finish,
Concealed Screw Mounting.
Matching Plastic Roller.
q 5808W – Paper Holder
White Finish,
Concealed Screw Mounting.
Matching Plastic Roller.
Cle
aning Instructions:
2 5 3 0 0 A L M O E N D R I V E N O R T H O L M S T E D , O H 4 4 0 7 0 ( 8 0 0 ) 3 2 1•- 8 8 0 9 •
F A X : (800) 8 4 8 - - 6 6 3 6 • I N T E R N A T I O N A L : ( 4 4 0 ) 9 6 2 20 0 0 •
F A X : ( 4 4 0 ) 9 6 2
-
2 7 2 6 C U S T O M E R S E R V I C E ( U S A ) : 8 0 0
-
882
-
0 1 1 6
1.
Position the mounting template on
the wall in the desired location. Using a
level, align the template and tape it to the wall.
2. Place each mounting plate on the template with “UP” facing you.
3. One at a time, place each anchor screw through the mounting plate, centered
in each large hole. Using a Phillips screwdriver, turn the anchor screw while
applying pressure. Screw will self drill and tap into drywall. Do not over
tighten.
4. Only insert screw ½ to ¾ of the way into wall.
5. l After all screws are installed, tear the template away from the wal
6. Tighten all 4 screws. Do not over tighten.
7. Position each end post with the setscrew down and place over mounting
plate. Tighten the setscrew at the bottom of each base.
8.
Compress the paper holder bar and place into both post holes.
Stock Number:
______________________Paper Holder
By CSI Bath Furnishings
Materials:
Installation Instructions:
Stock Numbers:
Dimensions:
Paper Holder
5808
Aspen Technical Specification
To preserve the fine finish of this product, clean only with a soft
damp cloth. Dry well. Do not use commercial or abrasive cleaners.
Copyright CSI Bath Furnishing Division of Moen 02/22/01
Literature #BA0966
