Nedis CATR120BK Handleiding
Hier is de Nedis CATR120BK (Hifi systeem) gebruikershandleiding. 22 pagina's in taal Alle talen met een gewicht van 2.2 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/22
a Quick start guide
FM Audio Transmitter CATR120BK
For more information see the extended manual online:
ned.is/catr120bk
Intended use
The product is exclusively intended for use in a vehicle with an
auxiliary power outlet.
The product is exclusively intended for streaming audio to a car's
FM radio, answering mobile phone calls via Bluetooth and charging
devices via USB.
Any modication of the product may have consequences for safety,
warranty and proper functioning.
Parts list [Image A]
1 Display
2 Main control knob
3 USB port (Music)
4 USB port (Charging)
5 Bass Booster
6 Previous song / Fast rewind
7 Next song / Fast forward
8 Auxiliary power plug
9 MicroSD card slot
Safety instructions
-
WARNING
• Only use the product as described in this manual.
• Be careful when using the product while driving. Always focus
your attention on the road.
• Do not use a damaged product.
• Do not expose the product to water or moisture.
• Do not drop the product and avoid bumping.
Installation [image B]
To prepare the product for wireless use:
1. Plug the product in an auxiliary power outlet.
4If the car battery voltage is lower than 12 V, the display will ash.
The product can still work well, but the car may have trouble
starting the engine at a voltage lower than 11.8 V. The product
will not function at a voltage lower than 8 V.
2. Tune your car radio to an unused FM frequency.
3. Press and hold
2 until the display starts ashing.
4. Rotate 2 to tune the product to the same frequency as your car
radio.
To connect your mobile phone to the product:
1. Activate Bluetooth on your phone and connect with the product
(CATR120BK).
2. If asked, enter the pairing code '0000'.
Play music [image C]
To stream music from the product to the FM radio, choose one of
the following options:
• Play music directly from the mobile device that is connected to
the product via Bluetooth.
• Insert a Micro SD card (q). The music on the card will play
automatically.
• Insert a USB drive (w). The music on the drive will play
automatically.
4Press and hold
5 for 2 seconds to switch between USB drive
mode, SD card mode and Bluetooth mode.
To control music that is playing:
• Press 2 to play or pause the music
• Rotate 2 to control the volume.
• Press 6 and 7 to switch between songs.
• Press and hold 7 to fast forward through a song.
• Press and hold 6 to rewind a song.
• Press 5 to activate the Bass Booster.
Answer phone calls
4When a call comes in while playing music, the product will
automatically switch to telephone mode.
• To answer an incoming call, press 2.
• To reject an incoming call, press and hold 2 for 2 seconds.
• During a call, press and hold 2 for 3 seconds to switch to private
mode.
• To call the previous number, press
2 twice.
4When making a call, you must dial the number on your phone.
Once the call connects, you can use the product's hands-free
function.
Charge a mobile device
To charge your device:
1. Plug the product in an auxiliary power outlet.
2. Connect your device to 4. Use an USB cable.
Specications
Product FM Audio Transmitter
Article number CATR120BK
Input voltage 12 - 24 V
Charger output 5 V / 2.4 A
USB output 5 V / 1.0 A
Wireless technologies FM
Bluetooth® 5.0
FM frequency range 87.6 - 107.9 MHz
Max. radio transmit power 2 dBm
Bluetooth frequency range 2400 - 2483.5 MHz
Bluetooth proles A2DP
HFP
Storage capacity 32 GB
Music formats MP3
WMA
FLAC
Display 20 x 8 x 4 mm
Bass Booster Yes
Hands-free calling Yes
Declaration of Conformity
We, Nedis B.V. declare as manufacturer that the product CATR120BK
from our brand Nedis®
, produced in China, has been tested
according to all relevant CE standards and regulations and that all
tests have been passed successfully. This includes, but is not limited
to the RED 2014/53/EU regulation.
The complete Declaration of Conformity (and the safety datasheet if
applicable) can be found and downloaded via webshop.nedis.com/
CATR120BK#support
For additional information regarding the compliance, contact the
customer service:
Web: www.nedis.com
E-mail: service@nedis.com
Phone: +31 (0)73-5991055 (during oce hours)
Nedis B.V., de Tweeling 28
5215 MC ’s-Hertogenbosch, the Netherlands
Probleemoplossing Nedis CATR120BK
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Ingebouwd display: | Ja |
| Gewicht: | 33.8 g |
| Breedte: | 38.7 mm |
| Diepte: | 85.3 mm |
| Hoogte: | 43.2 mm |
| Geïntegreerde klok: | Nee |
| Bluetooth: | Ja |
| Stroom: | 2 A |
| Beeldscherm: | LED |
| Beeldschermdiagonaal: | 1 " |
| Ondersteund audioformaat: | FLAC, MP3, WAV |
| USB-connectortype: | USB Type-A |
| Type aansluitplug: | Bluetooth |
| Type stroombron: | Sigarettenaansteker |
| Geïntegreerde geheugenkaartlezer: | Ja |
| Compatibele geheugenkaarten: | MicroSD (TransFlash) |
| Aantal USB 2.0-poorten: | 2 |
| Microfoon, line-in ingang: | Ja |
| DC voltage input: | 12 - 24 V |
| Materiaal: | ABS |
| Soort tuner: | Digitaal |
| Aansluiting: | Sigarettenaansteker |
| Frequentiebereik: | 20 - 20000 Hz |
| Spanning: | 5 V |
| Signaal/ruis-verhouding: | 65 dB |
| MP3 afspelen: | Ja |
| Ondersteunde frequentiebanden: | FM |
| Apple docking: | Nee |
| FM-band: | 87.6 - 107.9 MHz |
| Poort 1 uitgangsstroom: | 2.4 A |
| Poort 2 uitgangsstroom: | 1 A |
| Handsfree bellen: | Ja |
| Zendfrequentie: | 2.4 GHz |
