NM-W440WHITE NEWSTAR FLAT SCREEN WALL MOUNT
NewStar Products Europe B.V.
Wateringweg 62/B
2031 EJ HAARLEM
THE NETHERLANDS
Phone
Fax
Email
Website
: +31(0)23-5478888
: +31(0)23-5478889
: info@newstar.nl
: www.newstar.eu
NewStar cannot be held liable for any inaccuracies and copyrights.
No part of this publication may be reproduced and/or published by print, photocopy,
microfilm or in any other way, without prior written permission of
NewStar Computer Products Europe BV.
Newstar TV/Monitor Wall Mount (Full
Motion) for 23"-55" Screen - White
The NewStar wall mount, model NM-W440WHITE is a full swing tilt- and swivel wall mount
for flat screens up to 55”. This mount is a great choice when you want the ultimate viewing
flexibility with your flat screen TV. Effortless pull the display out from the wall, position it in
almost any direction, turn it around corners and then smoothly return it to the wall when
finished.
NewStars’ tilt (30°) and swivel (180°) technology allows the mount to change to any viewing
angle to fully benefit from the capabilities of the flat screen. The mount is easily depth
adjustable from 4 to 51 centimetres. An innovative cable management conceals and routes
cables from mount to flat screen. Hide your cables to keep living room, bedroom or home
cinema installation nice and tidy.
NewStar NM-W440WHITE has three pivot points and is suitable for screens up to 55" (140
cm). The weight capacity of this product is 25 kg each screen. The wall mount is suitable for
screens that meet VESA hole pattern 75x75 to 400x400mm. Different hole patterns can be
covered using NewStar VESA adapter plates.
Create a clean design ambiance for your flat screen TV in a living room, bedroom or public
environment.
All installation material is included with the product.
SPECIFICATIONS
Color
Distance to wall
Height adjustment
Max. screen size
Max. weight
Min. screen size
Min. weight
Screens
Swivel (degrees)
Tilt (degrees)
Type
VESA maximum
VESA minimum
Warranty
EAN code
White
4 - 51 cm
None
55
25
23
0
1
180°
25°
Tilt
Turn
Full motion
400x400 mm
75x75 mm
5 year
8717371444532
Downloaded from www.vandenborre.be
Probleemoplossing Newstar NM-W440
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Breedte verpakking: | 265 mm |
| Diepte verpakking: | 55 mm |
| Hoogte verpakking: | 350 mm |
| Montagewijze: | Muur |
| Land van herkomst: | China |
| Maximale gewichtscapaciteit: | 25 kg |
| Paneelmontage-interface: | 75 x 75, 400 x 400 mm |
| Netto gewicht kartonnen doos: | 15000 g |
| Netto gewicht pakket: | 3800 g |
| Draaihoek: | 5 ° |
| Montage interface compatibiliteit (min): | 75 x 75 mm |
| Montage interface compatibiliteit (max): | 400 x 400 mm |
| Aantal displays ondersteund: | 1 |
| (Buitenste) hoofdverpakking hoogte: | 370 mm |
| (Buitenste) hoofdverpakking breedte: | 250 mm |
| (Buitenste) hoofdverpakking brutogewicht: | 16600 g |
| (Buitenste) hoofdverpakking lengte: | 290 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 4 stuk(s) |
| Bereik kantelhoek: | 0 - 25 ° |
| Maximale schermgrootte: | 55 " |
| Code geharmoniseerd systeem (HS): | HS7326909890 |
| Producten per pallet (EU): | 180 stuk(s) |
| Minimale schermgrootte: | 23 " |
| Afstand tot de muur (min): | 40 mm |
| Afstand tot de muur (max.): | 510 mm |
