PT-VMZ71 Series
LCD Projectors
1 According to Panasonic research for the PT-VMZ71 only among LCD laser projectors in the 7,000-lumens-class or higher as of January 2022. 2 Full On/Full Off, when [PICTURE MODE] is set to [DYNAMIC] and [DYNAMIC CONTRAST] is set to [1]. Measurement, measuring conditions, and method
of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped. 3 For PT-VMZ71 only. For individual model specification, please refer to the specifications table. 4 Depending on the connected CEC command compatible device, the link control
may not operate normally. 5 Excluding PT-VMZ51S and PT-VMZ41. 6 Supports signals up to 4K/30p. A signal with different resolution is converted to the number of display dots. PT-VMZ71/VMZ61/VMZ51/VMZ51S/VMZ41: 1920 x 1200 dots, PT-VMW61/VMW51: 1280 x 800 dots. Applicable
terminals: DIGITAL LINK terminal/HDMI terminal. 7 Requires optional AJ-WM50 Series Wireless Module (sold separately). Availability may vary by country or region. 8 For more information on Wireless Presentation System PressIT, please visit https://panasonic.net/cns/prodisplays/pressit. Availability
may vary by country or region. 9 Measurement, measuring conditions, and method of notation all comply with ISO/IEC 21118: 2020 international standards. Value is average of all products when shipped. When [PICTURE MODE] is set to [DYNAMIC] and [LIGHT POWER] is set to [NORMAL].
Smallest and Lightest LCD Projector in Class1 Delivers Up to
7,000 l for Clear, Vivid Images in Well-Lit Classrooms and Officesm
PT- /PT- /PT-VMZ71 VMZ61 VMZ51/PT-VMZ51S
PT- /PT- /PT-VMZ41 VMW61 VMW51
Black Models
***
* **
PT-VMZ71 Series
7,000 lm
9
6,200 lm
9
5,200 lm
9
4,500 lm
9
6,200 lm
9
WUXGA WXGA
Resolution
Light Output
PT-VMZ71
5,200 lm
9
Main Features
White Models
* Supports signals up to 4K/30p. See specifications for details. ** PT-VMZ51S/VMZ41 excluded.
*** AJ-WM50 Series Wireless Module required.
Note: PT-VMZ71/VMZ61 only.
PT-VMZ61 PT-VMZ51/VMZ
51S
PT-VMZ41
PT-VMW61 PT-VMW51
1 According to Panasonic research for the PT-VMZ71 only among LCD laser projectors in the 7,000-lumens-class or higher as of January 2022.
Clear Images That Are
Easy to See in Bright Rooms
01
With up to 7,000 lm, 3,000,000:1 contrast2, Daylight View Basic,
and vivid 3-chip LCD color, images stay clear and bright in
well-lit classrooms and meeting rooms. Visually complex
images, such as detailed graphics and fine text, are crisp, sharp,
and easy to see even to those viewing the screen at a distance.
Installation Flexibility Adapts
Projection to Any Space
02
PT-VMZ71 Series is smallest and lightest LCD projector in its
class1. Compact 7.0 kg3 (15.43 lbs) body, 1.6x zoom, and
V/H Lens-Shift streamline installation while new 6-Point Screen
Adjustment enables projection into room corners. CEC command
compatible4 HDMI® and DIGITAL LINK5 support 4K input signals6.
Enjoy Smooth and
Effortless Collaboration
03
Connect smartphone and projector over wireless LAN 7 via the
QR Code displayed on screen and share a wide variety of content
without cable mess, or use optional Wireless Presentation
System PressIT8 to share almost any device screen at the press
of a button. You can also project content from USB flash drive.
Note: Model availability varies by country or region.
Probleemoplossing Panasonic PT-VMZ71
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Wit |
| Ingebouwd display: | Nee |
| Gewicht: | 7000 g |
| Breedte: | 399 mm |
| Diepte: | 348 mm |
| Hoogte: | 115 mm |
| Geluidsniveau: | 37 dB |
| Materiaal behuizing: | Kunststof |
| Stroombron: | AC |
| Oorspronkelijke beeldverhouding: | 16:10 |
| Ethernet LAN: | Ja |
| Ondersteunde video-modi: | 1080p |
| Geïntegreerde geheugenkaartlezer: | Nee |
| Typische contrastverhouding: | 3000000:1 |
| Zoomcapaciteit: | Ja |
| Markt positionering: | Draagbaar |
| Projector helderheid: | 7000 ANSI lumens |
| Projectietechnologie: | LCD |
| Projector native resolution: | WUXGA (1920x1200) |
| Keystone correctie, verticaal: | -25 - 25 ° |
| Keystone correctie, horizontaal: | -35 - 35 ° |
| Geschikt voor schermmaten: | 30 - 300 " |
| Projectie-afstand objectief: | - m |
| Aantal USB 2.0-poorten: | 1 |
| VGA (D-Sub)poort(en): | 2 |
| Aantal HDMI-poorten: | 2 |
| Soort serieële aansluiting: | RS-232C |
| Audio-ingang (L, R): | 1 |
| PC audio ingang: | Ja |
| PC Audio-uitgang: | Ja |
| HDMI-connector type: | Volledige grootte |
| DVI-poort: | Nee |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Smart TV: | Nee |
| Focus: | Handmatig |
| Zoom type: | Handmatig |
| Diafragma (F-F): | 1.6 - 2.12 |
| Brandpuntbereik: | 15.3 - 24.64 mm |
| Levensduur van de lichtbron: | 20000 uur |
| Type lichtbron: | LED |
| Ingebouwde luidsprekers: | Ja |
| Gemiddeld vermogen: | 10 W |
| Aantal ingebouwde luidsprekers: | 1 |
| Stroomverbruik (in standby): | - W |
| Throw ratio: | 1.09 - 1.77:1 |
| Formaat analoog signaal: | Niet ondersteund |
| Volledige HD: | Ja |
| 3D: | Nee |
| Ondersteunde grafische resoluties: | 1920 x 1080 (HD 1080) |
| Audio (L,R) out: | 1 |
| PC-ingang (D-Sub): | Ja |
| Matrix type: | 3-panel (p-Si TFT actief) |
| Geluidsniveau (spaarzame modus): | 27 dB |
| Eenvormigheid: | 85 procent |
| Horizontale lens verplaatsingsbereik: | -20 - 20 procent |
| Verticale lens verplaatsingsbereik: | 0 - 44 procent |
| Wifi: | Nee |
| AC-ingangsspanning: | 100 - 240 V |
| AC-ingangsfrequentie: | 50/60 Hz |
| Stroomverbruik (typisch): | 375 W |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 20 - 80 procent |
| Type product: | Projector met normale projectieafstand |
