INSTALLATION INSTRUCTIONS PR143N-AST
© Panduit Corp. 2014
www.panduit.com
For instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp
E-mail:
techsupport@panduit.com
Phone:
866-405-6654
Rev. 03Page 1 of 1
INSTALLATION INSTRUCTIONS PR143N-AST
© Panduit Corp. 2014
www.panduit.com
For instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp
E-mail:
techsupport@panduit.com
Phone:
866-405-6654
Rev. 03Page 1 of 1
1. Snap groove portion of tie onto
support strand.
2. Position cable against tie spacer
and thread tail through slot in
head. Push upwards on body of
tie until snug.
3. Use pliers utilizing tension steps
on tie to tighten completely.
4. Support tie shown when properly
installed. If releasability is not
required, tip can be cut off.
TO RELEASE:
Use screwdriver to push locking tab
towards support strand.
Tab
1. Snap groove portion of tie onto
support strand.
2. Position cable against tie spacer
and thread tail through slot in
head. Push upwards on body of
tie until snug.
3. Use pliers utilizing tension steps
on tie to tighten completely.
4. Support tie shown when properly
installed. If releasability is not
required, tip can be cut off.
TO RELEASE:
Use screwdriver to push locking tab
towards support strand.
Tab
Aerial Support Ties
Part Numbers: AST10-5-C100, AST15-5-C100,
AST20-5-C100, AST25-5-C100
Aerial Support Ties
Part Numbers: AST10-5-C100, AST15-5-C100,
AST20-5-C100, AST25-5-C100
Probleemoplossing Panduit AST20-5-C100
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Soort: | Bevestigingssokkel |
| Materiaal: | Polypropyleen (PP) |
| Aantal per verpakking: | 100 stuk(s) |
| Identificatielabel: | Ja |
