Docking Cradle Speaker System waDC700
Connect
Install
Enjoy
Quick Start guide
C
B
A
Specifications are subject to change without notice.
Trademarks aree the property of Koninklijke Philips Electronics N.V. or their respective owners.
2006 © Koninklijke Philips Electronics N.V. All rights reserved.
www.philips.com
What's in the box
CountryCountry HelpdeskHelpdesk Tariff / minTariff / min Keep readyKeep ready
0820 901115
070 253 010
3525 8761
09 2290 1908
08 9165 0006
0180 5 007 532
0 0800 3122 1223
01 601 1161
199 404 042
26 84 30 00
0900 0400 063
2270 8250
2 1359 1440
902 888 785
08 632 0016
02 2310 2116
0906 1010 017
Troubleshootting
Problem Solution
No sound
No any response
after pressed the
buttons on the
remote control
Sound can't be
adjusted
Sound distorted
Sound isn’t loud
enough
• Check if the audio cable is well connected
• Check if the power cable of the speakers is well connected
• Check if Pipe Speaker power is turned on.
• Check if the power cord to the docking station is well connected
• Point the remote control to the docking station. The remote
control is designed for the docking station instead of your iPod
or GoGear.
• Check if the plastic protective sheet has been removed
• Check if the battery of the remote control is used up. If yes,
replace it with a new one
• Some functions buttons do not applicable for GoGear
(see Enjoy section for details.)
• Check if the audio cable is properly connected: the audio cable
should be connected to the black 3.5mm jack in the middle of
the backside of the docking station.
• Set EQ to 'Off" status:
a. Press MENU
b. Press 3or 4to select EQ and then press OK to confirm
c. Press 3or 4to select Off and then press OK to confirm
• The voltage output level of your iPod decided the pipe
speaker's maximum volume
Need help?
Online help: www.philips.com/support
Contact line: 1 800 531 0039
Docking cradle 8 x iPod dock adaptorPipe speaker
AC adapter
Quick Start Guide
Audio Cable
Remote control with
one CR2032 battery
pre-installed
AC Power cord
3 x GoGear dock
adaptors
DC Cable
Important!
The docking cradle only supports the devices listed below.
Do not try it on any other device!
- Apple iPod (iPod video, iPod nano, iPod Photo and iPod
mini)
- Philips GoGear HDD players (Charge function optional)
iPod GoGear
or
What else you’ll need
Specifications
Sound
Loudspeakers
Dock Connectivity
Remote Control
- Output Power : 2 x 15 Watts RMS
- Sound Enhancement : Class "D" Amplifier
- Main Speaker : 4 x Nano Speakers, front firing
with adjustable angle.
- Subwoofer : 4 x Pipe Shaped Woofers
- Audio Out : 3.5 mm (Cable Provided )
- AV Out : 3.5 mm for Audio/Video Out ( Cable Optional )
- DC in for iPod : 3mm (Cable Provided )
- DC in for GoGear and iPod : 9 pins ( Cable Optional )
- USB : Mini USB ( Cable Optional )
- Remote Control : IR build-in
- 10 Keys Remote Control for iPod and GoGear Portable Player
Probleemoplossing Philips WADC700
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Black, Grey |
| Breedte: | 150 mm |
| Diepte: | 220 mm |
| Hoogte: | 150 mm |
| Gewicht verpakking: | 5500 g |
| Breedte verpakking: | 302 mm |
| Diepte verpakking: | 200 mm |
| Hoogte verpakking: | 540 mm |
| Bluetooth: | Nee |
| Type aansluitplug: | 3,5 mm |
| Snelstartgids: | Ja |
| Garantiekaart: | Ja |
| Afmetingen verpakking (BxDxH): | 302 x 200 x 540 mm |
| Gemiddeld vermogen: | 30 W |
| Volumeregeling: | Digitaal |
| Afspeel modi: | Fast backward, Fast forward, Next, Previous |
| Audio-uitgangskanalen: | - kanalen |
| Compatibiliteit: | iPod player\r\nGoGear player |
| Breedte van het apparaat: | 150 mm |
| Laadmechanisme: | Bovenkant |
| Apple docking-compatibiliteit: | iPod |
| Diepte van de hoofd luidspreker: | 200 mm |
| Hoogte van de hoofd luidspeker: | 150 mm |
| Breedte van de hoofd luidspreker: | 150 mm |
| AC-ingangsspanning: | 100 - 240 V |
| AC-ingangsfrequentie: | 50 - 60 Hz |
