WIRELESS HUMIDITY AND
TEMPERATURE DATA LOGGER
DATA SHEET
Transport and storage of perishable goods (food, wine, etc.)
Transport and storage of sensitive products (medical, biological, etc.)
• Transport and storage of precious objects (furniture, paintings, musical instruments, etc.)
• Wireless measurement in sealed containers (laboratories, R&D, etc.)
Technical specications
Parameter Humidity Temperature
Range 0 to 100 %RH -40 to 70 °C / -40 to 158 °F
Accuracy
Typ. ±2.0 %RH
Max. ±4.5 %RH (10 %RH-90 %RH)
Max. ±7.5 %RH (<10 %RH, >90 %RH)
Typ. ±0.2 °C / ±0.4 °F
Max. ±0.4 °C / ±0.8 °F (0 °C - 65 °C / 32 °F - 149 °F)
Max. ±1.0 °C / ±1.8 °F (<0 °C, >65 °C / <32 °F, >149 °F)
Resolution 0.06 %RH 0.09 °C / 0.09 °F
Drift <0.25 %RH/year <0.03 °C / <0.06 °C /year
General features
Battery Button cell: CR2450 (non-replaceable)
Standards & Directives 2014/53/EU; EMV 2014/30/EU; RoHS 3; Reach
Protection IP 68
Autonomy (with a
540 mAh battery)
3.5 years with 1 measurement per second
8 years with 1 measurement every 10 seconds
Recording capacity
Temperature on 11 bits, res. 0.09 °C / Humidity on 11 bits, res. 0.06%:
Min. 172,000 temperature/humidity recordings.
120-day history with one measurement per minute.
Operating conditions
(°C, °F / %RH / m, p1-yd /
MPa, bar)
-40 to 70 °C / -40 to 158 °F
Working pressure (experimental laboratory tests):
Working altitude: 0 to 2000 m / 0 to +2188 p1-yd
Working absolute pressure: 0.05 MPa to 2 MPa (20 bar)
Typical RH error, with absolute air pressure:
0.05 MPa to 0.3 MPa (3 bars): -0.35% /MPa (-0.035% /bar)
0.3 MPa to 2 MPa (20 bars): -0.49% /MPa (-0.049% /bar)
Storage temperature -40 to 70 °C / -40 to 158 °F
Bluetooth
Frequency band: Bluetooth LE 2402MHz to 2480MHz ISM Band
Maximum RF output power: < 4 dBm
BLE 5.0 Low Energy. Range: 10 m / 32’ without obstacles
DS_EN – KH30 – 09/05/25 - Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.
Dimensions
31.8 mm / 1 16/64’’
24 mm / 60/64’’
3.5 mm / 9/64’’
38 mm / 1 32/64’’
1
2
3
4
5
6
1 - Low Energy wireless communication - Data recording
2 - IP68 sealed shell
3 - Easy to attach
4 - Integrated CR2450 battery. Battery life up to 8 years
5 - LED indication and identication
6 - High precision temperature and humidity sensor
Description
KH 30
Maximum tolerance
Typical tolerance
Operating range
Maximum tolerance
Typical tolerance
Operating range
FREE
APP
Kimo Track
Secure app for accessing temperature and humidity graphs
sauermanngroup.com
Kimo, a Sauermann brand.
