VGA to HDMI Converter
VGA TO HDMI CONVERTER THAT
SUPPORTS STEREO AUDIO IN
AND INFRARED DEVICES
Quick Start Guide
VGA VIDEO IN
Format VGA
Resolution
480i, 480p, 576i, 576p, 720p,
1080i, 1080p (24/25/30Hz
DDC Via AUX
Input Equalization Automatic
Input Cable Length Up to 25 ft
Output Cable Length Up to 25 ft
HDMI VIDEO OUT
Format HDMI 1.3 Supported
HDCP Compliance 1.0/1.1
Video Bandwidth Single-link 340MHz (10.2 Gbps)
Resolution
480i, 480p, 720i, 720p, 1080i,
1080p (24/25/30Hz)
Output Interface
(1) HDMI (7.1 Channel audio and
video)
Connector Type A (19-Pin Female)
Maximum Distance Up to 25 ft
AUDIO
Signal Type
DTS-HD/Dolby-TrueHD/LPCM7.1/
DTS/Dolby-AC3/DSD
Input Interface (1) 3.5mm Audio In (Female)
OTHER
Power
External 100-240 VAC/5VDC4A
@10W
Dimensions 2.5” W x 7/8” H x 2 1/4” D
Weight 0.5lb per V2 unit
Operating Temp. 0-55 °C (32-131°F)
Storage Temp. -20-85 °C (-4-185 °F)
Humidity Up to 95%
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
800.AVI.2131, 702.800.0005
2455 W Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
SmartAVI.com
TECHNICAL SPECIFICATION
CVH-01
WHAT’S IN THE BOX
PART NO. Q-TY DESCRIPTION
CVH-01 1 VGA to HDMI Converter
PS5VDC2A 1 PS5VDC2A Power Supply
Quick Start Guide 1
Probleemoplossing Smart-AVI CVH-01
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Breedte: | 127 mm |
| Diepte: | 76.2 mm |
| Hoogte: | 25.4 mm |
| Ondersteunde video-modi: | 1080i, 1080p, 480p, 720i, 720p |
| Maximale videoresolutie: | 1920 x 1200 Pixels |
| Plug and play: | Ja |
| Stroomvoorziening via USB: | Nee |
| Hostinterface: | VGA |
| Bandbreedte: | 1.65 Gbit/s |
| Operating voltage: | 5 V |
| Output interface: | HDMI |
| Werkzame stroming: | 2 A |
