SaviStreamer E300
Encoder
Quick Start Guide
800.AVI.2131
Tel: (818) 503-6200 | Fax: (818) 503-6208
11651 Vanowen St. North Hollywood, CA 91605
SmartAVI.com
NOTICE
The information contained in this document is subject
to change without notice. SmartAVI makes no
warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for particular purpose.
SmartAVI will not be liable for errors contained herein
or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
20170525
Capture and stream or record high-
definition A/V signals from a media
source and create a seamless
extension over IP to one or more
decoder units
Full HD, Low-Bandwidth
1080p Streaming Encoder
TECHNICAL SPECIFICATIONS
VIDEO
Format HDMI 1.4 / VGA
DVI Compliance Single-link DVI-D 1.1 w/ adaptor
HDCP Compliance 1.0/1.1
Resolution
Up to 3840 x 2160 @30Hz
Outputs
(1) HDMI Local loop with Digital L-
PCM Audio, (1) VGA HD15 Analog
Inputs
(1) HDMI with Digital L-PCM Audio,
DVI with HDMI to DVI adapter
Maximum Cable
Length
HDMI 20 ft.
Video Stream
Output
MPEG-4 Part 10 / AVC (H.264)
AUDIO
Audio Input (1) 3.5 mm, analog stereo
Audio Output
(1) 3.5 mm local loop, analog ste-
reo
Audio Stream
Support
MPEG4-GENERIC, MPEG4-LATM
OTHER
Network
Connector
(1) RJ-45
Streaming
Protocols
RTP, RTSP, RTCP, UDP
Command
Protocols
TCP/IP, UPnP, HTTPS
USB
(1) Type B Female, Firmware up-
date only
RS-232
(1) DB9 Female, Function forth-
coming
Compression H.264/Mpeg4 Part 10 (AVC)
4 Pin-Din
Connector
Power, Do not use.
Power Adapter PS5VDC4A
Dimensions 9” W x 4” D x 1.8” H
Weight .75 lbs.
Working Temp. 32 to 113°F (0 to 45 °C )
Working Humidity 20 to 80% RH (no condensation)
Storage Temp. -40 to 131°F (-40 to 55 °C )
Storage Humidity 5 to 95% RH (no condensation)
WHAT’S IN THE BOX
PART NO. QTY DESCRIPTION
SAVI-ST-E300 1
1080p H.264 Streaming
Encoder
PS5VDC4A 1 Power Adapter
1 Quick Start Guide
Probleemoplossing Smart-AVI E300
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 340.1 g |
| Videocompressieformaten: | H.264, MPEG4 |
| Maximale beeldsnelheid: | - fps |
| VGA (D-Sub)poort(en): | 1 |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Aansluiting voor netstroomadapter: | Ja |
| Maximale videoresolutie: | 1920 x 1080 Pixels |
| RS-232 port: | 1 |
| Aantal HDMI-invoerpoorten: | 1 |
| Temperatuur bij opslag: | -40 - 55 °C |
| Ondersteunde netwerkprotocollen: | s RTP, RTSP, RTCP, UDP, TCP/IP, UPnP, HTTPS |
| Afmetingen (B x D x H): | 228.6 x 101.6 x 45.72 mm |
| Bedrijfstemperatuur (T-T): | 0 - 45 °C |
