FX-USB
www.smartavi.com
Installation
Manual
What’s in the Box?
Technical Specications
OTHER
Power External 100-240 VAC/5VDC4A @20W
Dimensions 7 in W x 1 in H x 4.5 in D
Weight 2.0 lbs. (0.9 kg)
Operating Temp. 0-55 °C (32-131°F)
Storage Temp. -20-85 °C (-4-185 °F)
Humidity Up to 95%
OPTICAL
Fiber Type Single, multi mode
Connector Type Duplex LC
Wavelength 1310 nm/1550 nm (Dual wavelength)
Data Rate 5 Gbps (2.5 Gbps per single wavelength)
Transmission Power -5 dB Min.
Receiver Sensitivity -21 dB Max
Distance 500 m Max.
USB
Signal Type EHCI (USB 2.0) and OHCI/UHCI (USB 1.1)
Input Interface (TX) (1) USB Type B (Female)
Output Interface (RX) (4) USB Type A (Female)
PART NO. QTY DESCRIPTION
FX-TXUSB 1 USB 2.0 Fiber Extender Transmitter
FX-RXUSB 1 USB 2.0 Fiber Extender Receiver
PS5VDC4A 2 5 Volt 4 Amp Power Supply
CCUSBAB06 1 6ft USB MM AB cable
© Copyright 2011 Smart-AVI, All Rights Reserved
NOTICE
The information contained in this document
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
For more information, visit www.smartavi.com.
SmartAVI, Inc. / Twitter: smartavi
11651 Vanowen St. North Hollywood, CA 91605
Tel: (818) 503-6200 Fax: (818) 503-6208
http://www.SmartAVI.com
Rack Mountable Option
Our SmartRack is the perfect solution to allow
virtually all SmartAVI devices to be custom mounted
in a standard 19” server rack. The SmartRack is fully
adjustable and can secure/organize several devices.
USB 2.0 Extender up to 1,500 feet
over Fiber Optic Cable
Probleemoplossing Smart-AVI FX-USB
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 900 g |
| Breedte: | 101.6 mm |
| Diepte: | 76.2 mm |
| Hoogte: | 25.4 mm |
| Aantal USB 2.0-poorten: | 5 |
| Temperatuur bij opslag: | -20 - 85 °C |
| Maximaal bereik: | 4577.2 m |
| Bedrijfstemperatuur (T-T): | 0 - 55 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 95 procent |
