TECHNICAL SPECIFICATIONS WHAT’S IN THE BOX
VIDEO
Fornat HDMI2.0
Input Interface (16) HDMI 19-pin
Output Interface (1) HDMI 19-pin
Resolution
Up to 4K (3840 x 2160 @ 30 Hz);
Up to 1920 x 1080 @ 60Hz (DVI-D)
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft
Output Cable Length Up to 20 ft
USB
Signal Type USB 2.0, 1.1, and 1.0 w/ internal hub
Input Interface (16) USB Type B
Output Interface
(2) USB 1.1 Type A for KVM Devices;
(2) USB 2.0 Type A Transparent
CONTROL
Front Panel Push Buttons with LED Indicators
RS-232 Via Control @ 115200 bps
Hot Keys Via Keyboard
OSD Via KM arrow keys
OTHER
Power
External 100-240 VAC/ 12VDC3A
@ 24W
Dimensions 17.0” W x 2.7” H x 8.69” D
Weight 6.9 lbs
Approvals UL, CE, ROHS Compliant
Operating Temp. 32 to +104°F (0 to +40°C)
Storage Temp. -4 to 140°F (-20 to +60°C)
Humidity Up to 80% (no condensation)
Emulation Keyboard and Mouse
PART NO. QTY DESCRIPTION
SM-UHO-16P 1
SH 16-Port HDMI KVM Switch with
USB 2.0 Support and OSD
PS12VDC3A 1
12-VDC, 3-A power adapter with
center-pin positive polarity.
1 Quick Start Guide
DESIGNED
AND MADE
IN THE USA
NOTICE
The information contained in this document
is subject to change without notice. iPGARD
makes no warranty of any kind with regard
to this material, including but not limited to,
implied warranties of merchantability and
tness for a particular purpose. iPGARD
will not be liable for errors contained
herein, or for incidental or consequential
damages in connection with the furnishing,
performance, or use of this material. No
part of this document may be photocopied,
reproduced, or translated into another
language without the prior written consent
from iPGARD, Inc.
20170518
Toll Free: (888)-994-7427
Phone: (702) 800-0005
Fax: (702)-441-5590
WWW.iPGARD.COM
A full manual can be downloaded from
www.ipgard.com/documentation/
SM-UHO-16P
16-Port HDMI KVM Switch
with USB 2.0 Sharing and OSD
Quick Start Guide
