Smeg PV175B3 Handleiding
Hier is de Smeg PV175B3 (Fornuis) gebruikershandleiding. 17 pagina's in taal Engels met een gewicht van 1,636,230.0 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/17
22 - PRECAUTIONS 91477A886/A
PRECAUTIONS 22
General safety instructions 22
Installation 25
Appliance purpose 26
This user manual 27
Manufacturer’s liability 27
Identification plate 27
Disposal 27
Energy efficiency information 27
To save energy 27
How to read the user manual 28
DESCRIPTION 28
General description 28
USE 29
Precautions 29
Preliminary operations 29
Available accessories 29
Using the hob 29
CLEANING AND MAINTENANCE 30
Cleaning the hob 30
Cleaning the hob 31
What to do if... 31
INSTALLATION 32
Gas connection 32
Gas types and Countries 35
Burner and nozzle specifications tables 35
Electrical connection 36
Section cut from the countertop 36
Mounting 37
Fixing to the built-in cabinet 38
Instructions for the installer 38
We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com
These instructions apply only to the destination countries listed on the appliance's data plate.
This is a class 3 built-in hob.
PRECAUTIONS
General safety instructions
Risk of personal injury
• During use the appliance and
its accessible parts become
very hot. Keep children well
away from the appliance.
• Protect hands with heat resistant
gloves during use.
• Never try to put out a fire or
flames with water: Turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children under the age of
eight at a safe distance unless
they are constantly supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
• Cleaning and maintenance
must not be carried out by
Probleemoplossing Smeg PV175B3
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Apparaatplaatsing: | Ingebouwd |
| Soort bediening: | Draaiknop |
| Kleur van het product: | Zwart |
| Ingebouwd display: | Nee |
| Gewicht: | 17300 g |
| Breedte: | 720 mm |
| Diepte: | 510 mm |
| Hoogte: | 48 mm |
| Snoerlengte: | 1.2 m |
| Gewicht verpakking: | 19300 g |
| Breedte verpakking: | 860 mm |
| Diepte verpakking: | 610 mm |
| Hoogte verpakking: | 155 mm |
| Soort materiaal (bovenkant): | Glas/roestvrij staal |
| Vermogen brander/kookzone 2: | 1700 W |
| Vermogen brander/kookzone 3: | 3200 W |
| Vermogen brander/kookzone 1: | 1100 W |
| Aantal branders/kookzones: | 5 zone(s) |
| Type kookplaat: | Gaskookplaat |
| Type brander/kookzone 1: | Klein |
| Type brander/kookzone 2: | Medium |
| Type brander/kookzone 3: | Groot |
| Aantal gaspitten: | 5 zone(s) |
| Aantal elektronische kook zones: | 0 zone(s) |
| Controle positie: | Voorkant |
| Aangesloten lading (elektrisch): | - W |
| Installatie compartiment breedte: | 560 mm |
| Aangesloten lading (gas): | 10300 W |
| Breedte kookplaat: | 70 cm |
| Installatie compartiment diepte (min): | 482 mm |
| Type brander/kookzone 4: | Medium |
| Vermogen brander/kookzone 4: | 2600 W |
| Voedingsbron brander/kookzone 1: | Gas |
| Voedingsbron brander/kookzone 2: | Gas |
| Voedingsbron brander/kookzone 3: | Gas |
| Voedingsbron brander/kookzone 4: | Gas |
| Installatie compartiment diepte (max): | 486 mm |
| Positie brander/kookzone 1: | Links voor |
| Positie brander/kookzone 2: | Links achter |
| Positie brander/kookzone 3: | Centraal |
| Positie brander/kookzone 4: | Rechts achter |
| Kookzone 1 vorm: | Rond |
| Kookzone 2 vorm: | Rond |
| Kookzone 3 vorm: | Rond |
| Kookzone 4 vorm: | Rond |
| AC-ingangsspanning: | 220 - 240 V |
| AC-ingangsfrequentie: | 50 - 60 Hz |
| Inbouw afzuigkap: | Nee |
| Voedingsbron brander/kookzone 5: | Gas |
| Type brander/kookzone 5: | Klein |
| Positie brander/kookzone 5: | Rechts voor |
| Vermogen brander/kookzone 5: | 1700 W |
| Kookzone 5 vorm: | Rond |
