Contents
19
1. Precautions for safety and use ________________________ 20
2. Fitting the appliance in the top ________________________ 21
2.1 _______________________________________21 Fixing to the supporting structure
2.2 Fitting the adhesive foam rubber strip ____________________________________22
2.3 _________________________________________________22 Fitting the xing clips
2.4 Fitting the hob into the hole in the work- top________________________________22
3. Electrical connection ________________________________ 23
4. Gas connection ____________________________________ 24
4.1 _______________________________________________24 Bottled gas connection
4.2 ____________________________________________________24 Room ventilation
4.3 ____________________________________________24 Combustion gas discharge
5. Adapting to different types of gas ______________________ 25
5.1 _______________________________________________25 Removing the hob skin
5.2 ______________________________________________26 Adjusting for bottled gas
5.3 ______________________________________________26 Adjusting for natural gas
5.4 Adjusting the primary air ow ___________________________________________26
5.5 ____________________________________________27 Reassembling the hob skin
5.6 ______________________________27 Adjusting the minimum setting for natural ga
5.7 ____________________________________27 Adjusting the minimum for bottled gas
5.8 ___________________________________________________27 Hob burner layout
5.9 ________________________________________________27 Greasing the gas taps
6. Description of controls ______________________________ 28
6.1 The front panel ______________________________________________________28
7. Using the hob _____________________________________ 29
7.1 ________________________________________________29 Fitting the pan stands
7.2 ______________________________________32 Lighting burners with safety device
7.3 _____________________________________32 Practical hints for using the burners
7.4 ______________________________________________________32 Pan diameters
8. Cleaning and maintenance ___________________________ 33
8.1 ____________________________________________________33 Cleaning the hob
8.2 Cleaning instructions for an acid-etched glass hob __________________________33
8.3 _____________________________________________33 Cleaning the components
THESE INSTRUCTIONS ONLY APPLY TO THE COUNTRIES OF DESTINATION WHOSE
IDENTIFICATION SYMBOLS ARE LISTED ON THE COVER OF THIS MANUAL.
THIS BUILT-IN HOB IS CLASSIFIED AS CLASS 3.
INSTRUCTIONS FOR THE INSTALLER: these are intended for the qualied
engineer who is to check the gas supply system and install, commission and test the
appliance.
INSTRUCTIONS FOR THE USER: these provide recommendations for use, a
description of the controls and the correct procedures for cleaning and maintaining the
appliance.
Further information about the products can be found at www.smeg.com
