Smeg SE495ETD Handleiding
Hier is de Smeg SE495ETD (Fornuis) gebruikershandleiding. 19 pagina's in taal Engels met een gewicht van 1,690,170.0 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/19
PRECAUTIONS - 2391477B059/A
e
PRECAUTIONS 23
General safety instructions 23
Installation 26
Appliance purpose 27
This user manual 27
Manufacturer’s liability 27
Identification plate 27
Disposal 27
To save energy 28
How to read the user manual 28
DESCRIPTION 29
Control panel 30
USE 31
Preliminary operations 31
Basic functions 31
Using the hob 31
Additional functions 33
Safety functions 34
CLEANING AND MAINTENANCE 35
Cleaning the glass ceramic hob 35
What to do if... 36
INSTALLATION 36
Electrical connection 36
Power limitation procedure (60 cm models) 38
Power limitation procedure (80/90 cm models) 38
Section cut from the countertop 38
Mounting 40
Fixing to the built-in cabinet 41
Fixing to the built-in cabinet 41
Instructions for the installer 41
We advise you to read this manual carefully, which contains all the instructions for maintaining the
appliance’s aesthetic and functional qualities. For further information on the product: www.smeg.com
PRECAUTIONS
General safety instructions
Risk of personal injury
• During use the appliance and
its accessible parts become
very hot. Keep children well
away from the appliance.
• The appliance becomes very
hot during use. Take care never
to touch the heating elements.
• Protect your hands by using
oven gloves when handling hot
pans.
• Never try to put out a fire or
flames with water: turn off the
appliance and smother the
flames with a fire blanket or
other appropriate cover.
• This appliance may only be
used by children aged 8 years
and over, and by people of
reduced physical, sensory or
mental capacity, or lacking in
experience in the use of
electrical appliances, provided
that they are supervised or
have been given instructions on
the safe use of the appliance
and of the hazards associated
with it.
• Children must not play with the
appliance.
• Keep children below the age
of 8 away from the appliance
unless they are constantly
supervised.
• Keep children under the age of
8 away from the appliance
when it is in use.
• Cleaning and maintenance
must not be carried out by
unsupervised children.
• Be aware of how rapidly the
Probleemoplossing Smeg SE495ETD
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Apparaatplaatsing: | Ingebouwd |
| Soort bediening: | Touch |
| Kleur van het product: | Zwart |
| Aantal vermogenniveau's: | 9 |
| Ingebouwd display: | Ja |
| Timer: | Ja |
| Gewicht: | 13200 g |
| Breedte: | 900 mm |
| Diepte: | 510 mm |
| Hoogte: | 50 mm |
| Snoerlengte: | 1.5 m |
| Kinderslot: | Ja |
| Gewicht verpakking: | 15000 g |
| Breedte verpakking: | 1000 mm |
| Diepte verpakking: | 620 mm |
| Hoogte verpakking: | 130 mm |
| Geïntegreerde klok: | Ja |
| Soort klok: | Elektronisch |
| Warmhoud functie: | Ja |
| Soort materiaal (bovenkant): | Glaskeramiek |
| Aantal branders/kookzones: | 5 zone(s) |
| Type kookplaat: | Keramisch |
| Type brander/kookzone 1: | Dubbele zone |
| Type brander/kookzone 3: | Drie zones |
| Aantal gaspitten: | - zone(s) |
| Aantal elektronische kook zones: | 5 zone(s) |
| Controle positie: | Voorkant |
| Aangesloten lading (elektrisch): | 9100 W |
| Installatie compartiment breedte: | 850 mm |
| Aan/uitschakelaar: | Ja |
| Aangesloten lading (gas): | - W |
| Type timer: | Digitaal |
| Breedte kookplaat: | 90 cm |
| Boost functie: | Ja |
| Aantal boosters: | 5 |
| Installatie compartiment diepte (min): | 490 mm |
| Douane productcode (TARIC): | 8516605000 |
| Kleur bedieningspaneel: | Zwart |
| Bescherming tegen overstromen: | Ja |
| Restwarmte-indicator: | Ja |
| Hoogte onder werkblad: | 20 mm |
| Voedingsbron brander/kookzone 1: | Electrisch |
| Voedingsbron brander/kookzone 2: | Electrisch |
| Voedingsbron brander/kookzone 4: | Electrisch |
| Installatie compartiment diepte (max): | 514 mm |
| Timer duur: | 99 min |
| Oververhittingsbeveiliging: | Ja |
| Positie brander/kookzone 1: | Links voor |
| Diameter brander/kookzone 1: | 185 mm |
| Positie brander/kookzone 2: | Links achter |
| Diameter brander/kookzone 2: | 150 mm |
| Positie brander/kookzone 3: | Centraal |
| Diameter brander/kookzone 3: | 290 mm |
| Positie brander/kookzone 4: | Rechts achter |
| Diameter brander/kookzone 4: | 200 mm |
| Klaar alarm: | Ja |
| Type stroomaansluiting: | Stekker |
| Stekker: | Ja |
| Quick start: | Ja |
| AC-ingangsspanning: | 220 - 240 V |
| AC-ingangsfrequentie: | 50 - 60 Hz |
| Type beeldscherm: | LED |
| Aantal fases: | 3 |
| Resttijdindicator: | Ja |
| Voedingsbron brander/kookzone 5: | Electrisch |
| Positie brander/kookzone 5: | Rechts voor |
| Diameter brander/kookzone 5: | 150 mm |
| Randprofiel: | Recht |
| Aantal timers voor einde kookproces: | 5 |
| Aantal minutentellers: | 1 |
