Digital Still Camera
Startup Guide
5-063-959-11(1)
DSC-RX1RM3
Preparations
Checking the supplied items
The number in parentheses indicates the number of pieces.
• Camera (1)
• Rechargeable battery pack
NP-FW50 (1)
• Shoulder strap (1)
• Lens cap (1) (attached to the
camera)
• Shoe cap (1) (attached to the
camera)
• Eyepiece cup (1)
• Wrapping cloth (1)
• Startup Guide (this manual) (1)
• Reference Guide (1)
Inserting the battery pack (supplied)/memory card
(sold separately) into the camera
Open the battery/memory card cover, and insert the battery pack and
a memory card into the camera. Then, close the cover.
Insert the battery pack while
pressing the lock lever.
Ensure the notched corner
faces correctly.
This camera is compatible with SD memory cards.
When you use a memory card with this camera for the first time,
format the card using the camera in order to stabilize the performance
of the memory card.
About the “Help Guide”
For detailed instructions on using the camera, refer
to the “Help Guide” (web manual).
https://rd1.sony.net/help/dsc/2510/h_zz/
DSC-RX1RM3 Help Guide
Charging the battery pack
Charge lamp
To an external power
source
Turn the power off.
• If the camera is turned on, the battery pack
will not be charged.
Connect the USB Type-C® terminal of the
camera to the USB Type-C terminal of
a device compatible with USB PD (USB
Power Delivery) using a commercially
available USB Type-C cable (USB-C® –
USB-C).
• The charge lamp will light up when charging
starts. When the charge lamp turns off,
charging is completed.
Use a USB-PD-compatible device with an output of 18W (9V/2A) or
more and a USB Type-C cable (USB-C – USB-C) that supports 3A or
more.
Performing initial setup for the camera
By establishing a Bluetooth connection (pairing) between the camera
and a smartphone, you can perform initial camera setup such as
date and time settings from the smartphone. Install the smartphone
application on your smartphone in advance, and then follow steps
to
under “Procedures for initial camera setup.”
Installing the smartphone application
Install the application from the following website.
Also, update to the latest version of the smartphone
application.
https://www.sony.net/ca/
Procedures for initial camera setup
ON/OFF (Power) switch
Control wheel/
center button
Set the ON/OFF (Power) switch to “ON” to
turn on the camera.
Select the desired language and then
press the center of the control wheel.
• The setting screen for the screen reader
function and a privacy notice will appear. Read
the privacy notice regarding biometrics by
opening the link using your smartphone, etc.
Press the center of the control wheel.
Follow the instructions on the camera
screen to connect the camera with your
smartphone and perform the initial
setup.
• You can also configure or change the initial
settings later from the MENU of the camera.
Connecting (pairing) the camera with your smartphone later
For details on the connection method, refer to the
following Help Guide URL:
https://rd1.sony.net/help/dsc/2510_pairing/h_zz/
Shooting
Shooting still images
Mode dial
Shutter button
Select the desired shooting mode by
turning the mode dial.
Press the shutter button halfway down
to focus.
Press the shutter button all the way
down.
Shooting movies
Turn and set the mode dial to (Movie), and then press the
shutter button to start recording.
Press the shutter button again to stop recording.
Attaching the eyepiece cup (supplied)
The eyepiece cup shades the area between the viewfinder and your
eye to keep out light. Attaching the eyepiece cup improves the visibility
of the viewfinder.
Loosen the screw on the eyepiece cup until it can no longer be turned,
and then attach the eyepiece cup straight onto the viewfinder and
tighten the screw to lock the eyepiece cup into place.
Viewing and developing RAW
images on a computer
Install the computer software from the following website. Update the
computer software to the latest version before using it.
https://www.sony.net/disoft/help/
Using the wrapping cloth
(supplied)
When carrying the camera, you can protect the camera
from scratches and dirt by using the wrapping cloth
(supplied). For details on how to use the wrapping cloth,
refer to the Help Guide:
https://rd1.sony.net/help/dsc/2510_wrapping/h_zz/
Notes on use
Refer to “Precautions” in the “Help Guide” as well.
About the applications for smartphones/computers
The specifications of the applications may change without notice.
Notes on handling the product
• Do not leave the lens or the viewfinder exposed to a strong light source such as sunlight.
Because of the lens’s condensing function, doing so may cause smoke, fire, or a
malfunction inside the camera body or the lens. If you have to leave the camera exposed
to a light source such as sunlight, attach the lens cap to the lens.
• If sunlight or other strong light enters the camera through the lens, it may focus inside
the camera and cause smoke or fire. Attach the lens cap when storing the camera. When
shooting with backlighting, keep the sun sufficiently far away from the angle of view.
Even if it is slightly away from the angle of view, smoke or fire may still occur.
• This camera (including accessories) has magnet(s) which may interfere with pacemakers,
programmable shunt valves for hydrocephalus treatment, or other medical devices.
Do not place this camera close to persons who use such medical devices. Consult your
doctor before using this camera if you use any such medical device.
• Increase the volume gradually. Sudden loud noises can damage your ears.
• Do not leave this unit, the supplied accessories, or memory cards within the reach of
infants. They may be accidentally swallowed. If this occurs, consult a doctor immediately.
• When shooting with the viewfinder, you may experience symptoms such as eyestrain,
fatigue, motion sickness, or nausea. We recommend that you take a break at regular
intervals when you are shooting with the viewfinder.
• If the monitor or electronic viewfinder is damaged, stop using the camera immediately.
The damaged parts may harm your hands, face, etc.
• When shooting still images continuously, the monitor or viewfinder may flash between
the shooting screen and a black screen. If you keep watching the screen in this situation,
you may experience uncomfortable symptoms such as feeling of unwellness. If you
experience uncomfortable symptoms, stop using the camera, and consult your doctor
as necessary.
• When recording for long periods of time or recording 4K movies, if the same part of
your skin touches the camera for a long period of time while using the camera, even if
the camera does not feel hot to you, it may cause symptoms of a low-temperature burn
such as redness or blistering. Pay special attention in the following situations and use a
tripod, etc.
- When using the camera in a high temperature environment
- When someone with poor circulation or impaired skin sensation uses the camera
- When using the camera with [Auto Power OFF Temp.] set to [High]
Sony accessories
Using this unit with products from other manufacturers may affect its performance,
leading to accidents or malfunction.
WW697160/WW402748
