Key Features
SNC-DH120T
Network HD Camera —E series
Vandal-Resistant 720p HD Security Camera
• IK10-rated vandal-resistant feature to protect the camera
from destructive behaviors.
• Easy Focus/Easy Zoom functions for easy installation.
• Optical Day/Night function to switch to Day or Night
mode depending on the light level.
• Recording software (RealShot Manager Lite) is bundled
to start recording and monitoring instantly.
• Stream Squared function allows simultaneous streaming
of two 4:3 aspect ratio videos in user selectable SD
resolutions. User can select the entire image or a portion
of the image from the original eld of view and resize to
SD resolution or lower for each stream. With this feature,
the SNC-DH120T can replace two SD cameras installed in
the same line of view.
Excellent 720p HD picture quality, supporting
H.264 at 30 fps
1.3 Megapixel (1280 x 1024) maximum resolution
Three codecs (H.264, MPEG-4, JPEG) and a dual
streaming capability
The Exmor™ CMOS sensor incorporated to deliver
high image quality and low noise
Example
• DEPA™ Intelligent Video Analytics
system can be set up with a DEPA-
enabled recorder.
• Analog monitor output (phono jack).
• Powered by PoE (Power over Ethernet)
for simple installation.
• ONVIF™ (Open Network Video Interface
Forum) software that ensures greater
interoperability and more exibility in
building multiple-vendor systems.
1st Streaming
VGA video of a whole
Dual
Streaming
2nd Streaming
VGA video of a cropped area
(Simulated Images)
Probleemoplossing Sony SNCDH120T
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Gewicht: | 945 g |
| Gebruikershandleiding: | Ja |
| Montage gereedschap: | Ja |
| Ondersteunde videoformaten: | H.264,MPEG4 |
| Ondersteuning voor plaatsing: | Binnen |
| Ethernet LAN: | Ja |
| Maximum resolutie: | 329 x 1049 Pixels |
| Totaal aantal megapixels: | 1.4 MP |
| Type stroombron: | Power over Ethernet (PoE) |
| Minimale belichting: | 0.30 Lux |
| Meegeleverde kabels: | LAN (RJ-45) |
| Nachtvisie: | Ja |
| Video bewegings-detectie: | Ja |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Brandpuntbereik: | 3.1 - 8.9 mm |
| Certificering: | UL2044, FCC 15B Class A, IC Class A, IEC60950-1, EN55022(A)+EN55024+EN50130-4, VCCI Class A,\nC-Tick Class A\n |
| Formaat analoog signaal: | NTSC,PAL |
| Omvang optische sensor: | 1/3 " |
| Type beeldsensor: | CMOS |
| Optische zoom: | 2.9 x |
| Camera sluitertijd: | 1 - 1/10000 s |
| Witbalans: | Auto,Manual |
| Ondersteunde grafische resoluties: | 720 x 480,1280 x 960,1024 x 768 (XGA),1280 x 1024 (SXGA),1280 x 720 (HD 720),640 x 480 (VGA) |
| Bekabelingstechnologie: | 10/100Base-T(X) |
| Temperatuur bij opslag: | -20 - 60 °C |
| Maximaal 30 frames per seconde: | 30 fps |
| Compatibele besturingssystemen: | Microsoft Windows XP/ Vista(32bit)/7 (32bit) |
| Ondersteunde netwerkprotocollen: | Pv4, IPv6, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, FTP (client only), SMTP, DHCP, DNS,NTP, RTP/RTCP, RTSP, SNMP (MIB-2) |
| Power over Ethernet (PoE): | Ja |
| Minimale processor: | Intel Core2 Duo 2 GHz |
| Minimale RAM: | 1024 MB |
| Overdrachtssnelheid: | 100 Mbit/s |
| Stroomverbruik (typisch): | 6 W |
| Bedrijfstemperatuur (T-T): | -10 - 50 °C |
| F-nummer (relatieve aperture): | F1.2, F2.1 |
| Kijkhoek lens, horizontaal: | 85.4 ° |
| Actieve ombevoegde demontage alarm: | Ja |
