200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
FEATURES
4MP Flexible Intensifier® HD-TVI Bullet Camera
with Junction Box, Wall/Ceiling Mount, Dual voltage
H4FB2M
– 2.7~12mm motorized zoom focus lens, dark gray housing
SPECIFICATIONS
Image Sensor.................. 1/2.8” SONY Starvis 5MP Sensor
Minimum Illumination....... 0.00 lux (IR LED ‘on’)
Effective Pixels................ 2616 (H) x 1964 (V)
Total Pixels...................... 2704 (H) x 2104 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Video Output.................... 1.0Vp-p / 75 Ohms
Electronic Shutter............ Auto / Manual (1/30 – 1/30,000 sec.)
WDR................................ On (Low / Middle / High) / Off
Day / Night....................... Auto / Intensifier
Test Monitor Output......... TVI out
Power............................. 12VDC / 24VAC
Power Consumption........ 900mA max. (DC), 700mA max. (AC)
Operating Temperature.... -40
° F – 140
° F
Unit Dimensions.............. 9.64” (L) x 3.72” (Dia.)
Unit Weight...................... 2 lbs (camera), 0.9 lbs (junction box)
Certifications.................... FCC, RoHS
• Flexible Intensifier Technology
®
fits any lighting application
• Supports 4MP @ 30FPS
• True WDR operation
• Adaptive IR LED’s
• Presets: Outdoor, Low Light, Hallway, Lobby, Elevator, Indoor
• Built-in heater and anti-fog glass reduces condensation
• 3-axis for wall and ceiling mounting
• Full OSD and Zoom / Focus control through on-board and UTC
• Signal distance up to 1600 feet*
• Vandal / tamper resistant
• IP67 compliant, weather resistant
• 12VDC & 24VAC dual voltage operation
• 5 year warranty
OSD MENU TREE
PRESET MODE
• OUTDOOR
• INDOOR
• LOW LIGHT
• LOBBY
• HALLWAY
• ELEVATOR
MAIN SETUP
EXPOSURE
• LOW • MIDDLE • HIGH
• SHARPNESS • GAMMA • MIRROR
• FLIP
DAY / NIGHT
COLOR
SPECO DNR
EXIT
• BRIGHTNESS • SHUTTER
BACKLIGHT
• HLC• BLC
• WDR
• AUTO
• AWB • COLOR GAIN
• ACE • DEFOG
SYSTEM
• INTENSIFY • AGC
• INTENSIFIER
IRIS
MOTION
• SHADING
• CAMERA TITLE
• COMM • IMAGE RANGE
• COLOR SPACE
• OUTPUT
• LANGUAGE
• COLOR BAR
• RESET
OSD CONTROL
• D-ZOOM
• PRIVACY
MOTORIZED
INTCM1
(Pole/Corner Mount)
DIMENSIONS
Camera
Optional Accessories
Unit : inch
Junction Box
included
OSD Joystick
Video Test (TVI OUT)
Right (Near)
Up (Zoom-In)
Down (Zoom-Out)
Left (Far)
