INTCM1
(Pole/Corner Mount)
200 New Highway, Amityville, NY 11701
800 645- -5516 / www.specotech.com
DIMENSIONS
FEATURES
HD-TVI 1080p 2MP Intense IR Bullet Camera
Wall/Ceiling Mount, UTC, 2BNC out for TVI & CVBS, Dual voltage
HT7040TM – 2.8~12mm motorized zoom focus lens, dark gray housing
SPECIFICATIONS
Image Sensor.................. 1/2.9” Progressive Scan CMOS, 2MP
Minimum Illumination....... 0.00 lux (IR LED on)
Effective Pixels................ 1984 (H) x 1105 (V)
Total Pixels...................... 2000 (H) x 1121 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Output Resolution............ 1920x1080 @ 30fps
Video Output.................... 1.0Vp-p / 75 Ohms
Electronic Shutter............ Auto / Manual (1/30 – 1/30,000 sec.)
Day / Night....................... Auto / Color / BW / External
Test Monitor Output......... CVBS (BNC out in Yellow)
Communication............... UTC (up the coax)
Power............................. 12VDC / 24VAC
Power Consumption........ 900mA max. (DC), 750mA max. (AC)
Operating Temperature.... -4 –°F 122°F
Unit Dimensions.............. 9.64” (L) x 3.72” (Dia.)
Unit Weight...................... 2 lbs (camera), 0.9lbs (junction box)
Certifications.................... FCC, RoHS
Signal Distance............... Up to 1600 feet
(depending on coax quality)*
• Full HD resolution over coax (HD-TVI)
• Supports up to Full HD 1080p @ 30fps
• True WDR operation
• Intense IR function – no saturation, IR intensity adapts
to subject to provide vivid image
• Built- -in heater and anti fog glass reduces condensation
• 3-axis for wall and ceiling mounting
• Full OSD operation through on board control and UTC (up the coax) -
• Additional 960H analog output
• Signal distance up to 1600 feet*
• IP67 compliant, weather resistant
• 12VDC & 24VAC dual voltage operation
• 5 year warranty
OSD MENU TREE
Camera Optional Accessories
Unit : inch
MAIN SETUP
EXPOSURE
•B/W •EXTERN
• • •LOW MIDDLE HIGH
• • •SHARPNESS GAMMA MIRROR •FLIP
DAY / NIGHT
COLOR
SPECO DNR
EXIT
•BRIGHTNESS •SHUTTER
BACKLIGHT
•HLC•BLC•WDR
•AUTO
• •AWB COLOR GAIN
• •ACE DEFOG
SYSTEM
• •OUTPUT FREQ. •IMAGE RANGE
•INTENSIFY •AGC
•COLOR
IRIS
MOTION
•FRAME RATE
•LANGUAGE•COLOR BAR •RESET•CAM TITLE
•PRIVACY
2-MOTOR
•COLOR SPACE
•COM.
Junction Box
included
OSD Joystick
Video Test (CVBS)
Right (Near)
Up (Zoom-In)
Down (Zoom-Out)
Left (Far)
OSD CONTROL
