Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
Manual Revision: June 20, 2022 4:53 PM
Product Diagram (ADJ-TABLET-STAND-W)
Front View
Component Function
1Clamp
• For up to 12.9 in . on either side Tablets Holders
support the in placeTablet
• Width range from 5 to 8 in (12.8 to 22.4 cm)
• Maximum thickness 0.4 in (1.1 cm)
• Allow to rotate 360°, up and down, and side to side
2
Rotation Adjustment
Knob
• Varies the resistance of the or xes it Rotation Clamp
on a specic position
3
Clamp Tilt
Adjustment Screw
• Adjust the of the of the Resistance Tilt Angle Clamp
4
Support Arm Tilt
Adjustment Screws
• Adjust the of the of the Resistance Tilt Angle Upper
and sections of the Lower Support Arm
5Support Arm
• Supports the weight of the and provides Tablet
Height Tilt Adjustment and
6Mounting Holes • Allow to x the on a permanent locationTablet Stand
7Base
• Supports the in place. at the Assembly Foam Pads
bottom protect the desk or table surface
Universal Tablet Desk Stand - White
Package Contents
• Tablet Stand x 1
• 4.2x19 mm Wood Screws x 4
• 3 mm Hex Key x 1
• 5 mm Hex Key x 1
• Quick-Start Guide x 1
Requirements
For the latest manuals, product information, technical specications, and declarations of
conformance, please visit: www.startech.com/ADJ-TABLET-STAND-W
• Phillips head screwdriver
Operation
WARNINGS!
Do not exceed the weight capacity of this product. Overloading this product might
result in injury or property damage. This product can support the following weight: up
to 2.2 lb (1 kg).
When adjusting the tilt or height of this product, ensure that the mounted equipment
is properly secured and the weight is fully supported. Failure to follow these guidelines
may result in property damage and/or personal injury.
When not xed to a surface, always use two hands to ensure a controlled movement
when adjusting the height or tilt angle of this product to prevent tipping it over.
Is recommended to remove any protective case from the Tablet to t properly on the
Holders.
1. Slide the outwards to make enough room to mount the Holders Tablet Vertically
on the If the is enough, it can be mounted too. Clamp. Tablet Small Horizontally
Figure 1
7
6
1
5
2
4
4
3
*Product may vary from image
Probleemoplossing StarTech.com ADJ-TABLET-STAND-W
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Wit |
| Gewicht: | 1500 g |
| Breedte: | 160 mm |
| Diepte: | 160 mm |
| Hoogte: | 470 mm |
| Gewicht verpakking: | 1200 g |
| Breedte verpakking: | 320 mm |
| Diepte verpakking: | 180 mm |
| Hoogte verpakking: | 120 mm |
| Soort: | Multimedia-standaard |
| In hoogte verstelbaar: | Ja |
| Snelstartgids: | Ja |
| Maximale gewichtscapaciteit: | 1 kg |
| Materiaal: | Aluminium, Steel |
| Aantal per verpakking: | 1 stuk(s) |
| Aanbevolen gebruik: | Tablet |
| Draaibaar: | Ja |
| Inclusief moersleutel: | Ja |
| Draaihoek: | 185 ° |
| Aantal schroeven: | 4 |
| Aantal displays ondersteund: | 1 |
| (Buitenste) hoofdverpakking hoogte: | 370 mm |
| (Buitenste) hoofdverpakking breedte: | 655 mm |
| (Buitenste) hoofdverpakking lengte: | 375 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 12 stuk(s) |
| Maximale schermgrootte: | 12.9 " |
| Minimale schermgrootte: | 4.7 " |
| Type moersleutel: | Zeskantsleutel |
