Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 07/05/2013

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1x400WATXPowerSupply

• 1xPowerCord(NA)

• 1xInstructionManual

Installation

NOTE: Computerscontainsensitiveelectroniccomponentsthat

areeasilydamagedbystaticelectricityandexcessiveshock.When

handlingthepowersupplyandothercomponents,ensureyouare

properlygroundedusingananti-staticmatorsimilardevice.Ifanti-

staticequipmentisnotavailable,groundyourselfbytouchingthe

exteriorofthecomputercaseoranotherlargemetalsurfacebefore

handlinganyperipherals.

1. Installationofapowersupplyrequiressomemechanicalskill

andrequiresthatyouopenyourcomputercasetodisconnect

andreconnectwires.Ifyouareunfamiliarwiththiskindofwork,

considerbringingyourcomputerandnewStarTech.compower

supplytoyourlocalcomputerstoreforhelp.

2. Checktheredswitchontherearofthepowersupply,nextto

thepowercordplug.Besureitissettothecorrectvoltagefor

yourcountry.InNorthAmerica,itshouldread“115”.InEurope

andAustraliaitshouldread“230”.Tochangetheswitch,use

ascrewdriverinthenotchoftheswitchandslideittothe

oppositeside.Ifyouareunsureofthevoltageusedinyour

country,contactyourelectricityproviderbeforeproceeding.

3. Ifyouarereplacinganoldpowersupplyinyourcomputer,

ensurethecomputerisshutdownanddisconnectthepower

cordfromthebackoftheoldsupply.

4. Openyourcomputercase.Inmostdesigns,thecaseisopened

byremovingtwoorthreescrewsattherearofthecaseandthen

slidingthecoveringpanelbackwarduntilitcomesfree.Ifyour

caseisatowerstyle,ensurethatyouremovethepanelthatwill

exposethetopofthecomputer’smotherboard.Thisisgenerally

theleft-sidepanel.Therearemanydierentcasedesigns,

however,soifyouareunsureofhowtoopenyourparticular

case,consulttheusermanualforyourcaseorcontactyourlocal

computerstoreforhelp.

5. Withthecomputercaseopen,reviewtheconnectorsbeingused

fromyouroldpowersupply.Ifyouarebuildinganewcomputer,

reviewtheconnectorsthatyouwillneedtouse.Checkthetype

ofconnectoronyourmotherboardanduseeitherthe24or20

pinATXpowerconnectoronthepowersupplyasappropriate.

6. Disconnecttheoldpowersupplyconnectionsfrominside

yourcomputer.Harddiskdrive,CDdriveandoppydisk

driveconnectorsdisconnectbypullingontheconnector.The

motherboardconnector(s)haveaclipthatmustbepressed

whilepullingontheconnectortoreleasethem.Arocking

motionwhilepullingwillaidingettingtheconnectorsloose.

Neverpullonthewiresofaconnectortounplugit.

7. Checkthatallthewiresfromyouroldpowersupplyarefree.

Removethefourscrewsontherearofyouroldpowersupplyto

freeitfromthecomputercase.Supportthepowersupplywith

onehandifitcouldfallwhileremovingthelastscrew.(Suchasin

atowerstylecase.)Removethepowersupplybyslidingitback

andthenoutthroughthesideofyourcase.

8. Installyournewpowersupplybypositioningitthroughthe

sideortopofyourcase(dependingonyourcasestyle)andthen

backontothepowersupplymounts.Checkthattheorientation

withthescrewholesinyourcaseiscorrect;allfourholesmust

bealigned.Supportthepowersupplywithonehandwhile

threadingamountingscrewthroughthebackofthecaseand

ATX2POW400HS

400 Watt 20/24-pin Silent ATX 2.01 Computer Power Supply

*actual product may vary from photos

Probleemoplossing StarTech.com ATX2POW400HS

Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp

Specificaties

Gewicht:	1900 g
Hoogte:	86 mm
Gewicht verpakking:	2300 g
Breedte verpakking:	98 mm
Diepte verpakking:	235 mm
Hoogte verpakking:	215 mm
Totaal vermogen:	400 W
Bekabelingstype:	Niet-modulair
