Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: November 27, 2019 1:42 PM
Product Diagram (CABSHF2POSTV2)
Component Function
1Mounting Bracket • Used to mount the within a .Shelf Rack
2Shelf • Used to support equipment within a .Rack
• Maximum weight capacity = 75 lb (34 kg).
3Mounting Holes • Used to secure the to a .Shelf Rack
4Air Vents
• , Used to allow air to pass through the Air Vents
providing cooling for the equipment on the
Shelf.
Requirements
For the latest requirements, please visit www.startech.com/CABSHF2POSTV2
• (Optional) Cage Nut Tool x 1
• Phillips Head Screwdriver x 1
Installing the Shelf in a Rack
1. Determine the location within the that you want to install the .Rack Shelf
Note: The requires 2U of free space to mount within a . Shelf Rack
2. If the you are using has , insert the (2 Rack Square Mounting Holes M6 Cage Nuts
per ) into the on the . Insert Mounting Rail Square Mounting Holes Mounting Rails
one side of the (included) into the and push the M6 Cage Nut Square Mounting Hole
other side into the , until it locks into place.Square Mounting Hole
2-Post Rack Shelf with 20 Inch Depth
Note: Use a if you are having issues installing the Cage Nut Tool M6 Cages Nuts
into the .Rack
3. Align the on the with the (2 per Mounting Holes Bracket M6 Cages Nuts
Mounting Rail) installed in step 2.
4. Insert an (2 per ) through a (included) M6 Screw Mounting Rail M6 Plastic Washer
and through the on the and into the .Mounting Holes Bracket M6 Cage Nut
5. Using a tighten the , being careful not to Phillips Head Screwdriver M6 Screws
over-tighten.
Product Dimensions
Top
Front
1
23
4
