Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
Manual Revision: June 22, 2022 4:25 PM
Product Diagram (CMDUCT1UX2)
Front View
Component Function
1Mounting Ears • Secures the to the Duct Cable Management Panel
rack
2Duct Cover • Keeps cables out of the way and can be removed for
installation or upgrades
3Cable Management
Fingers
• Allows cables to be inserted and held in place
• Available along the length on both sides
4Duct Cover Latches
• Each corner of the Duct Cable Management Panel
has a latching mechanism that keeps the Duct Cover
in place
5Cable Path • Allow the inserted cables to run o to the side of the
Duct Cable Management Panel
Rear View
Component Function
1Pass-through Holes • Insert the cables through the Pass-through Holes
1U Horizontal Finger Duct Cable Management Panel for Racks - Includes Cover
Package Contents
• Horizontal Cable Duct x 1
• M6 Screws x 4
• M6 Cage Nuts x 4
• Washers x 4
• Quick-Start Guide x 1
Requirements
For the latest manuals, product information, technical specications, and declarations of
conformance, please visit: www.startech.com/CMDUCT1UX2
• Phillips head screwdriver
• Cage nut tool (Optional)
Installation
1. Determine the or on the of the rack U Height Number Mounting Location Posts
where to install the .Duct Cable Management Panel
2. Install the (x 4) onto the on theM6 Square Cage Nuts Square Cage Nut Holes
chosen . Use a if available or your preferred U Height Number Cage Nut Tool
installation method.
3. Align the with the previously inserted on the Mounting Ears M6 Square Cage Nuts
rack posts.
4. Insert the (x 4) onto the (x 4). Use a Washers M6 Screws Phillips Head Screwdriver
to install the (x 4) and fasten the to the M6 Screws Duct Cable Management Panel
Mounting Posts of the rack.
Operation
1. Insert the cables through the and the Cable Management Fingers Pass-through
Holes at the rear. Organize as desired.
2. Latch and secure the using the four .Duct Cover Duct Cover Latches
1
5
4
3
1
2
