Quick-Start Guide
Manual Revision: March 18, 2024
For additional self-service support options and community forums, please visit: www.StarTech.com/support
Product ID
DOCK-NUC-VESA-MOUNT
Component Function
1
Device VESA
Mounting Points
• VESA Compatible 75x75mm 100x100mm and
• Use to mount a , , or other NUC Thin Client Computer
VESA Compatible accessories
2Mounting Slots
• Use to mount StarTech.com , Docking Stations Thin
Client Computer VESA Compatible , or other accessories
Note: Other non-StarTech.com Docking Stations may be
compatible if they have a 40x40mm Mounting Pattern
• are spaced 40mm between each Long Mounting Slots
other. Use to mount Docking Stations
• are spaced 54.7mm vertically and Short Mounting Slots
horizontally. Use to mount a or other compatible NUC
Thin Client VESA Mount Bracketcomputer without a
3
Monitor VESA
Mounting Points
• and VESA Compatible 75x75mm 100x100mm
Package Contents
• VESA Adapter Mount For NUC ( ) x 1A
• M3 x 5mm Screws ( ) x 4B
• M3 x 16mm Screws ( ) x 4C
• M4 x 5mm Screws ( ) x 4D
• M4 x 12mm Screw ( ) x 4E
• M4 x 20mm Screws ( ) x 4F
• M5 x 12mm Screws ( ) x 4G
• M5 x 20mm Screws ( ) x 4H
• Washers ( ) x 4I
• Spacers ( ) x 8J
• Quick-Start Guide x 1
Requirements
For the latest requirements, please visit www.startech.com/DOCK-NUC-VESA-MOUNT
• Phillips head screwdriver
• (Optional) NUC or Thin Client specic VESA mount bracket
Installation
Attach a NUC or Compatible Thin Client
1 Without a VESA Mount Bracket
Note: Use two Screws on either the vertical or horizontal Short Mounting Slots.
VESA Compatible Mount for Docking Station, NUC, or Thin Client
3
2
*Product may vary from image
B or C
A
1
