Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: July 3, 2019 1:35 PM
Product Diagram (HB30A7AME)
Component Function
12-Wire Terminal Block • Used to connect an external DC Power Source
(7~48V DC Input) to the .Hub
2Screw Locks (x 8)
• Used to securely lock a to the USB Device
USB-A Port Hub on the .
• Center to center 19 Screw Lock Dimensions:
mm, thread size 4 - 40.
3Power LED • : Indicates that the Hub is receiving Green
power.
4USB-B Host Port
• Used to connect a to the .Host Computer Hub
• Center to center 24 Screw Lock Dimensions:
mm, thread size 4 - 40.
5USB-A Ports (x 7)
• Used to connect ( x 7) to the .USB Devices Hub
• Used to charge connected .USB-A Devices
• USB-A Ports support surge and 15KV ESD
(Electrostatic Discharge) Protection.
7-Port Industrial USB 3.0 (5 Gbps) Hub | USB 3.1 Gen 1 to 7x USB-A | ESD & Surge Protection
3
Requirements
For the latest requirements, please visit . www.startech.com/HB30A7AME
• Phillips Head Screwdriver
• Writing Utensil
• Level
• Mounting Screws (x 2)
Installation
Notes: It is recommended to use an external (+7 - 48V DC) DC Power Source
connected to the to ensure sucient power/current is 2-Wire Terminal Block
delivered to each on the . USB-A Port Hub
Powering the Hub Using the Universal Power Adapter
1. Connect the to the and to a Universal Power Adapter Terminal Block AC
Electrical Outlet.
2. Connect a (the end will depend on USB Port you are USB-B to USB Cable
connecting to) to the and to a USB port on the .USB-B Host Port Host Computer
3. The should detect the and automatically Host Computer’s Operating System Hub
install it.
4. Connect your to the (x 7) on the .USB Devices USB-A Ports Hub
Powering the Hub Using the 2-Wire Terminal Block
1. Remove the from the on the Terminal Block Connector Housing Terminal Block
Hub.
2. Using a small screwdriver (Phillips or Flat Head), loosen the screws on the Terminal
Block Connectors.
3. Connect the and from your (+7 - 48V DC) Power Ground Wires DC Power Source
to the proper , the terminals are marked on theTerminal Block Connectors Hub’s
Casing.
45
21
Probleemoplossing StarTech.com HB30A7AME
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 326 g |
| Breedte: | 55 mm |
| Diepte: | 145 mm |
| Hoogte: | 45 mm |
| Gewicht verpakking: | 1300 g |
| Breedte verpakking: | 190 mm |
| Diepte verpakking: | 294 mm |
| Hoogte verpakking: | 70 mm |
| LED-indicatoren: | Stroom |
| Stroom: | 1.4 A |
| Meegeleverde kabels: | USB |
| Inclusief AC-adapter: | Ja |
| Certificering: | RoHS, REACH, CE, FCC, TAA |
| Plug and play: | Ja |
| Aantal per verpakking: | 1 stuk(s) |
| Ingangsspanning: | 100 - 240 V |
| Soort voeding: | AC |
| Temperatuur bij opslag: | -20 - 85 °C |
| Aantal poorten USB 3.2 Gen 1 (3.1 Gen 1) Type A: | 7 |
| Output current: | 3.25 A |
| Spanning: | 20 V |
| Snelle installatiehandleiding: | Ja |
| Mean time between failures (MTBF): | 126106 uur |
| Hostinterface: | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| Chipset: | Genesys Logic - GL3523 |
| (Buitenste) hoofdverpakking hoogte: | 315 mm |
| (Buitenste) hoofdverpakking breedte: | 400 mm |
| (Buitenste) hoofdverpakking lengte: | 520 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 14 stuk(s) |
| Overdrachtssnelheid: | 5000 Mbit/s |
| Stroomverbruik (typisch): | 65 W |
| Bedrijfstemperatuur (T-T): | 0 - 70 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 95 procent |
| Code geharmoniseerd systeem (HS): | 84719000 |
| Aantal poorten: | 7 |
| Spanningsbeveiliging: | Ja |
| Inbegrepen soorten voedingsstekkers: | ANZ, EU, JP, NA, UK |
| Hub-interfaces: | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
| Klemmenblokpoort: | Ja |
| UASP-ondersteuning: | Ja |
| DIN-railset inbegrepen: | Ja |
