Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: June 2, 2020 2:55 PM
Product Diagram (IMC1GSFP)
Component Function
1PWR LED
• An external is Green: DC Power Source
detected.
• An external is not O: DC Power Source
detected.
2RJ45 Port
• Connect a to the Network Device Media
Converter.
Green LED:
• A is detected.On: Network Device
• The is Flashing: Media Converter
transmitting/receiving data.
3DIP Switch
DIP 1:
• Enables Link Fault Pass Through (LFP) On:
function. LFP highlights link failures, by forcing
a link down between both connections during
a link failure.
• Disables LFP function (default).O:
DIP 2:
• Sets SFP speeds to 1000Mbps (default).On:
• Sets SFP speeds to 100Mbps.O:
4SFP LED
• Indicates that a link is detected on the Green:
SFP.
• Indicates that data is being Flashing:
transmitted or received.
5SFP Slot
• Connect an (100/1000BASE-X) to the SFP
Media Converter.
Industrial RJ45 to Open SFP Media Converter | 1000 Mbps (1G)
64-Pin Terminal Block
• Connect an external (12-56V DC Power Source
DC Input) to the .Media Converter
• Connect an alarm or warning circuit to the
relay (ALM) connection. The relay is triggered if
the loses power.Media Converter
7Ground Screw
• Connect a ground connection to the Ground
Screw DC Power Source when connecting a to
the .Media Converter
Requirements
For the latest requirements, please visit www.startech.com/IMC1GSFP
• Network Equipment (ex. Router, Network Switch) x 1
• MSA-Compliant 100/1000BASE-X SFP Transceiver Module x 1
• RJ45 Terminated UTP/STP CAT5e (or better) Network Cable x 1
• Terminated Fiber Optic Cable (dependent on SFP Module) x 1
• DC Power Source x 1
• Phillips Head Screwdriver x 1
• Small Flat Head Screwdriver x 1
• Alarm or Warning Circuit x 1
Powering the Media Converter
Connecting and installing the must be completed by a 4-Wire Terminal Connector
licensed Electrician.
Notes: Make sure that you turn o the power source before connecting the power wire
to the .Media Converter
Do not exceed the recommend power source voltage as it may result in personal or
product damage.
1. Using a , loosen the two screws (+V-) on the Small Flat Head Screwdriver 4-Wire
Terminal Connector (included).
2. Connect the from a (12 - 56V DC), or the provided Power Wires DC Power Source
Barrel Power Connector Adapter Terminal Block Connectors to the proper on
the . The terminals are marked on the Media Converter Media Converter’s Casing
(connect the positive wire to V+ and the negative wire to V-).
3. (Optional) Using a , loosen the two screws (ALM) on Small Flat Head Screwdriver
the .4-Wire Terminal Connector
1 2
3 5 6
7
4
Probleemoplossing StarTech.com IMC1GSFP
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 144 g |
| Breedte: | 81.5 mm |
| Diepte: | 104 mm |
| Hoogte: | 32 mm |
| Type stekker: | Type N |
| Gewicht verpakking: | 386 g |
| Breedte verpakking: | 211 mm |
| Diepte verpakking: | 162 mm |
| Hoogte verpakking: | 64 mm |
| Materiaal behuizing: | Aluminium |
| Internationale veiligheidscode (IP): | IP30 |
| LED-indicatoren: | Ja |
| Gebruiksaanwijzing: | Ja |
| Connectiviteitstechnologie: | Bedraad |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Duurzaamheidscertificaten: | CE, RoHS |
| Ingangsspanning: | 12 - 56 V |
| Netwerkstandaard: | IEEE 802.3, IEEE 802.3x |
| Temperatuur bij opslag: | -40 - 85 °C |
| Intern: | Nee |
| Golflengte: | - nm |
| Mean time between failures (MTBF): | 569265 uur |
| Maximale overdrachtssnelheid van gegevens: | 1000 Mbit/s |
| Auto MDI/MDI-X: | Ja |
| Power over Ethernet (PoE): | Nee |
| Jumbo Frames ondersteuning: | Ja |
| (Buitenste) hoofdverpakking hoogte: | 225 mm |
| (Buitenste) hoofdverpakking breedte: | 355 mm |
| (Buitenste) hoofdverpakking lengte: | 345 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 10 stuk(s) |
| Maximaal bereik: | - m |
| Bedrijfstemperatuur (T-T): | -40 - 75 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 95 procent |
| Code geharmoniseerd systeem (HS): | 85176990 |
| Jumbo frames: | 9000 |
| DIN rail bevestiging: | Ja |
| Ondersteundende kabel types: | Cat6 |
| Vezel-optische connector: | SFP |
| Duplex systeem: | Volledig |
| Fibre channel-poorten: | 1 |
| Draad modus structuur: | Multi-mode, Single-mode |
