Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: September 11, 2020
Product Diagram (MONPROTECT)
Rear View
Component Function
1Cable Management
Hole
• Route the and for the Power Video Cables
Display Transparent through this opening in the
VESA Panel
2VESA Mounting Holes
• Insert 4 of the appropriately sized through Screws
the , the , the Washers VESA Mounts Transparent
VESA Panel 5 , the appropriate size and number of
mm 20 mm Spacers Display and/or , and into the
3Transparent VESA
Panel
• Clear acrylic sheet
• Weight - 8.3 lb. (3.76 kg)
• Three mounting heights
• Minimum mounting height (from Mounting
Surface VESA Mountto the middle of the ) - 9.7 in.
(245 mm)
Requirements
For the latest requirements, please visit:
www.startech.com/MONPROTECT
• Clean, Flat, and Stable Surface for Installation
• Display with 75 x 75 mm or 100 x 100 mm Spaced VESA Mounting Holes
Transparent VESA Panel - Single Display
• Monitor Mount with a Single VESA Mounting Point
Consult the for the or contact the of the User Manual Monitor Mount Manufacturer
Monitor Mount Monitor Mount to determine if the can support the combined weight
of the and the . Transparent VESA Panel Display
• Phillips Head Screwdriver
• Two People for Installation and Adjustments
• (Optional - for cleaning) Microber Cloth
Installation
Warnings: Installing the is a two person task. Do not Transparent VESA Panel
attempt to complete the installation with one person.
The additional weight of the may overload the Transparent VESA Panel Monitor
Mount during installation and/or use. Do not exceed the weight capacity of the
Monitor Mount.
(For a Display Already Attached to a Mount) Detach the Display
• Remove the from the .Display Monitor Mount
Note: Refer to the for steps on how to Monitor Mount Manufacturer’s User Manual
remove the from the .Display VESA Mount
Attach the Transparent VESA Panel
Figure 1
Screw
Washer
VESA Mount
20 mm Spacer
5 mm Spacer
VESA Mounting Holes
Display VESA
Mounting Holes
1
2
3
Probleemoplossing StarTech.com MONPROTECT
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Transparant |
| Gewicht: | 3700 g |
| Breedte: | 1100 mm |
| Diepte: | 889 mm |
| Hoogte: | 3 mm |
| Gewicht verpakking: | 6500 g |
| Breedte verpakking: | 1223 mm |
| Diepte verpakking: | 968 mm |
| Hoogte verpakking: | 52 mm |
| Gebruikershandleiding: | Ja |
| Materiaal: | Acryl |
| Duurzaamheidscertificaten: | CE, RoHS |
| Verbeterd kabelbeheer: | Ja |
| (Buitenste) hoofdverpakking hoogte: | 52 mm |
| (Buitenste) hoofdverpakking breedte: | 1223 mm |
| (Buitenste) hoofdverpakking lengte: | 968 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 1 stuk(s) |
| Hygiënisch: | Ja |
