Quick Start Guide
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 06/19/2015
For the latest information, technical specications, and support for
this product, please visit www.startech.com/<sku>.
Packaging contents
• 1x Mini DisplayPort to 3x HDMI MST Hub
• 1x Universal power adapter (NA/EU/UK/AUS)
• 1x Quick install guide
System requirements
• Mini DisplayPort 1.2 enabled computer
• Up to three displays with necessary cabling for HDMI support
Operating system requirements are subject to change. For the latest
requirements, please visit www.startech.com/MSTMDP123HD.
MSTMDP123HD
MST Hub - Mini DisplayPort to 3x HDMI
*actual product may vary from photos
Important operation notes
• Some computer systems may prevent this MST hub from
displaying digitally encrypted content.
• A computer, laptop or tablet with DisplayPort 1.2 is required for
MST support
• If your device only supports DisplayPort 1.1, the MST hub will
act as a splitter, automatically mirroring your video source across
all displays
• MST is certied for operation with Microsoft Windows 8 devices.
Other operating systems may adopt the technology. Please check
with your operating system vendor to conrm support. Operating
system support is subject to change. For the latest requirements,
please visit www.startech.com/MSTMDP123HD
• After the MST hub is attached, it may be necessary to initiate
operation of additional displays from within your Display settings
• The SCAN button resyncs all of the attached displays, and can be
utilized if any of the displays are not detected
• Certain graphics adapters such as the Intel based chips found on
the Microsoft Surface™ Pro 3, have limited MST support and will
only output to three displays in total. If you attach more than three
displays, all of the displays beyond that number will be disabled,
including the touch screen on the Surface Pro 3.
• MST shares 21.6 Gbps of bandwidth across all attached displays.
Higher resolutions can restrict the bandwidth available for the
remaining ports. Please see our guidelines below for determining
the ideal resolution for your setup
Product overview
Front View
Rear View
HDMI output ports
Integrated Mini
DisplayPort input
cable
SCAN button
Power
adapter port
Probleemoplossing StarTech.com MSTMDP123HD
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 119 g |
| Breedte: | 66 mm |
| Diepte: | 114 mm |
| Hoogte: | 14 mm |
| Gewicht verpakking: | 519 g |
| Breedte verpakking: | 152 mm |
| Diepte verpakking: | 240 mm |
| Hoogte verpakking: | 63 mm |
| Gebruikershandleiding: | Ja |
| Materiaal behuizing: | Kunststof |
| Stroom: | 0.5 A |
| Ondersteunde video-modi: | 1080p, 720p |
| Maximum resolutie: | 3840 x 2160 Pixels |
| Inclusief AC-adapter: | Ja |
| Certificering: | CE, FCC, REACH |
| Maximale refresh snelheid: | 30 Hz |
| Maximale videoresolutie: | 3840 x 2160 Pixels |
| HD type: | 4K Ultra HD |
| Ondersteunde grafische resoluties: | 1024 x 768 (XGA), 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA), 3840 x 2160 |
| Duurzaamheidscertificaten: | RoHS |
| Plug and play: | Ja |
| Ingangsspanning: | 100 - 240 V |
| Temperatuur bij opslag: | -20 - 70 °C |
| Compatibele besturingssystemen: | Windows 10 (32/64)\nWindows 8/8.1 (32/64)\nWindows 7(32/64) |
| Externe adapter: | Ja |
| Output current: | 3 A |
| Spanning: | 5 V |
| Hostinterface: | Mini DisplayPort |
| Video uit: | 3x HDMI |
| Chipset: | STDP4320 |
| Aansluiting video: | Mini DisplayPort |
| (Buitenste) hoofdverpakking hoogte: | 220 mm |
| (Buitenste) hoofdverpakking breedte: | 335 mm |
| (Buitenste) hoofdverpakking lengte: | 500 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 10 stuk(s) |
| AC-ingangsspanning: | 100 - 240 V |
| Stroomverbruik (typisch): | 15 W |
| Bedrijfstemperatuur (T-T): | 0 - 45 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 50 - 90 procent |
| Code geharmoniseerd systeem (HS): | 85176990 |
| Ondersteunende oplossingen: | 1024x768\n1280x720\n1920x1080\n1920x1200\n2560x1440\n2560x1600 |
| Output interface: | HDMI |
| Inbegrepen soorten voedingsstekkers: | AU, EU, NA, UK |
| Hoeveelheid Video ports: | 3 |
| Audio support: | Ja |
