Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
Manual Revision: June 1, 2023
Product Diagram
P021GI-NETWORK-CARD
Port/LED/Connector Function
1Bracket • Secures the card to the Host Computer Case
• The comes pre-installedFull Prole Bracket
2Open SFP Slot x 2 • Add a MSA-Compliant SFP Transceiver Module
• Supports or Fiber Ethernet 1 Gbps SFPs
3LED Indicators
• Left LED Indicator Link Speed is
• Solid Green: 1 Gbps
• Right LED Indicator Link Status is
• Solid Green: Active link
• Flashing Green: Activity
4PCIe 2.0 p1-x1 Connector • Insert into a on the PCI Express Slot Host Computer
Package Contents
• Open SFP Network Card x 1
• Low-Prole Bracket x 1
• Quick-Start Guide x 1
2-Port Open SFP Gigabit Network Card
Requirements
For the latest requirements, please visit www.startech.com/P021GI-NETWORK-CARD
• Host computer with an available PCI Express 2.0 or greater slot (x1, x2, x4, x8, or x16)
Installation
Install the PCI Express Card
WARNING!
Static Electricity PCI Express Cardscan severely damage . Ensure that you are
adequately before you open your or touch the Grounded Host Computer Case PCI
Express Card Anti-Static Strap Anti-Static Mat . You should wear an or use an when
installing any Host Computer component. If an isn’t available, Anti-Static Strap
discharge any built-up static electricity by touching a large Grounded Metal Surface
for several seconds. Only handle the by its edges and don’t touch PCI Express Card
the gold connectors.
1. Turn o the and any that are connected to it Host Computer Peripheral Devices
(e.g. printers, external hard drives, etc.).
2. Unplug the from the back of the .Power Cable Host Computer
3. Disconnect any that are connected to the .Peripheral Devices Host Computer
4. Remove the from the . Consult the documentation that Cover Host Computer Case
came with the for details about doing this safely.Host Computer
5. Locate an open and remove the corresponding PCI Express Slot Slot Cover Plate
from the back of the . Host Computer Case
Note: Consult the documentation that came with the for details Host Computer
about doing this safely. This card works in PCI Express x1, x2, x4, x8, or x16 Slots.
6. Gently insert the into the open and fasten the PCI Express Card PCI Express Slot
Bracket Host Computer Case to the back of the .
Note: If you install the into a or a PCI Express Card Small Form Factor Low Prole
Desktop System, it may be necessary to replace the pre-installed standard
Full Prole Bracket Low Prole Bracketwith the included .
7. Return the onto the .Cover Host Computer Case
8. Insert a compatible 1G SFP Transceiver Module SFP Slot PCI , into the onto the
Express Card.
9. Reconnect the to the back of the .Power Cable Host Computer
3
*Product may vary from image
1
4
2
Probleemoplossing StarTech.com P021GI-NETWORK-CARD
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Breedte: | 68 mm |
| Diepte: | 147 mm |
| Hoogte: | 10 mm |
| Gewicht verpakking: | 105 g |
| Breedte verpakking: | 140 mm |
| Diepte verpakking: | 170 mm |
| Hoogte verpakking: | 30 mm |
| LED-indicatoren: | Speed, Status |
| Connectiviteitstechnologie: | Bedraad |
| Interface: | Fiber |
| Netwerkstandaard: | IEEE 802.1AX, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3ap, IEEE 802.3az, IEEE 802.3z |
| Temperatuur bij opslag: | -10 - 70 °C |
| Intern: | Ja |
| Ondersteunde netwerkprotocollen: | IPv4, IPv6, TCP/UDP |
| Ondersteunt Linux: | Ja |
| Snelle installatiehandleiding: | Ja |
| Hostinterface: | PCI Express |
| Maximale overdrachtssnelheid van gegevens: | 1000 Mbit/s |
| Ondersteunde server operating systems: | Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Montagebeugels meegeleverd: | Ja |
| Jumbo Frames ondersteuning: | Ja |
| Full duplex: | Ja |
| Component voor: | PC |
| (Buitenste) hoofdverpakking hoogte: | 385 mm |
| (Buitenste) hoofdverpakking breedte: | 603 mm |
| (Buitenste) hoofdverpakking lengte: | 325 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 80 stuk(s) |
| Auto MDIX IEEE: | Ja |
| Stroomverbruik (typisch): | 2.8 W |
| Bedrijfstemperatuur (T-T): | 0 - 50 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 5 - 90 procent |
| Jumbo frames: | 9000 |
| Vezel-optische connector: | SFP |
| Fibre channel-poorten: | 2 |
| PCI versie: | 2.0 |
