Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: March 10, 2021
Product Diagram (PCI2S1P2)
Front View
Port Function
1Parallel Connector • Connect to the on the Parallel Pins PCI Card
2
Low-Prole Bracket
(Parallel)
• See Installing the Low-Prole Bracket(s)
3Parallel Port
• Connect a Parallel Peripheral Device
• DB-25 Parallel (Female)
4
Low-Prole Brackets
(Serial)
• See Installing the Low-Prole Bracket(s)
5Serial Ports
• Connect Serial Peripheral Devices
• DB-9 Parallel (Male)
6 PCI Connector
• Connect the to the in the PCI Card PCI Slot
Computer
Package Contents
• PCI Serial Parallel Combo Card x 1
• Full-Prole Bracket (Installed) x 1
• Low-Prole Brackets (for Serial Ports) x 2
• Low-Prole Bracket (for Parallel Port) x 1
• Quick-Start Guide x 1
2S1P PCI Serial Parallel Combo Card with 16C550 UART
Requirements
For the latest requirements, please visit:
www.startech.com/PCI2S1P2.
• Computer with an available PCI slot (x4/8/16)
• Needle-nose Pliers or 3/16 Nut Driver
Hardware Installation
Warning: PCI Cards can be damaged by static electricity. Make sure that the
Installer Computer Case is properly grounded before they open the or touch the PCI
Card. The should wear an when installing any computer Installer Anti-Static Strap
component. If an is not available, discharge any built-up static Anti-Static Strap
electricity by touching a large for several seconds. Only Grounded Metal Surface
handle the by its edges and do not touch the gold connectors. PCI Card
Installing the Low-Prole Bracket(s)
By default the is attached to the . Full-Prole Bracket Serial/Parallel Port(s)
Depending on the system conguration it may be necessary to remove the Full-
Prole Bracket(s) Low-Prole Bracket(s) to replace with the (included).
1. Remove the from both sides of each , using a Hexagonal Standos Port 3/16 Nut
Driver Needle-nose Pliersor a pair of .
2. Remove the and replace with the .Full-Prole Bracket(s) Low-Prole Bracket(s)
3. Install the removed in step 1. Thread the Hexagonal Standos Hexagonal
Standos Threaded Post 3/16 Nut Driver onto each and tighten, using a or a pair
of .Needle-nose Pliers
Installing the Card
1. Turn o the and any that are connected Computer Peripheral Devices
(e.g. printers, external hard drives, etc.).
2. Unplug the from the rear of the and disconnect any Power Cable Computer
Peripheral Devices that are connected.
3. Remove the from the . Cover Computer Case
Note: Consult the documentation that came with the for details about Computer
how to do this safely.
4. Locate an open and remove the corresponding from the PCI Slot Metal Cover Plate
rear of the . In most instances, the is attached Computer Case Metal Cover Plate
to the rear of the with a single . Save this for the next Computer Case Screw Screw
step.
6
3
2
5
4
1
Probleemoplossing StarTech.com PCI2S1P2
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 141 g |
| Breedte: | 21.6 mm |
| Diepte: | 134 mm |
| Hoogte: | 120 mm |
| Gewicht verpakking: | 190 g |
| Breedte verpakking: | 142 mm |
| Diepte verpakking: | 170 mm |
| Hoogte verpakking: | 30 mm |
| Gebruiksaanwijzing: | Ja |
| Soort serieële aansluiting: | RS-232 |
| Duurzaamheidscertificaten: | CE, RoHS |
| Temperatuur bij opslag: | -20 - 85 °C |
| Intern: | Ja |
| Ondersteunt Linux: | Ja |
| Hostinterface: | PCI/PCI-X |
| Ondersteunde server operating systems: | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Montagebeugels meegeleverd: | Ja |
| Seriële poort(en): | 2 |
| Chipset: | Asix - MCS9865 |
| (Buitenste) hoofdverpakking hoogte: | 340 mm |
| (Buitenste) hoofdverpakking breedte: | 360 mm |
| (Buitenste) hoofdverpakking lengte: | 385 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 40 stuk(s) |
| Bedrijfstemperatuur (T-T): | 0 - 70 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 10 - 90 procent |
| Code geharmoniseerd systeem (HS): | 84733020 |
| Uitbreidingskaart vormfactor: | Volledige hoogte / Laag profiel |
| FIFO (First In, First Out): | 256 B |
| Data transfer snelheid (max): | 0.0015 Gbit/s |
| Output interface: | Serie |
| Baud snelheid: | 115.2 Kbit/s |
| Data bits: | 5, 6,7, 8,9 |
| Stop bits: | 1, 1.5, 2 |
| Parity bit: | Even, Mark, N,Odd, Space |
| Flow Control type: | N, RTS/CTS, XON/XOFF |
