Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: February 7, 2019 10:23 AM
Product Diagram (PEX1S953LP)
Port Function
1Serial Port • Used to connect a Serial Device
2Screws
• Used to attach the Serial Port to the Bracket
• Used to secure a Serial Cable to the Serial Port
3Bracket • Used to attach the Card to your Computer
4
PCI Express Bus
Connector
• Used to connect the PCI Express Serial Card to
your Computer’s Motherboard
5Jumper • Used to congure Serial Port power settings
6Printed Circuit Board
• Components such as Jumpers are located on
this Board
7LP4 Power Connector • Used to connect a Power Source
1-Port PCI Express Serial Card with 16950 UART - Low-Prole
Requirements
• PCIe Slot
• Needle-Nose Pliers
For the latest requirements and full manual, please visit
www.startech.com/PEX1S953LP.
Installation
WARNING!
PCI Express Serial Cards can be severely damaged by static electricity. Make sure
that you are properly grounded before you open your or touch the Computer Case
PCI Express Serial Card Anti-Static Strap. You should wear an when you install any
computer component. If an isn’t available, discharge any built-up Anti-Static Strap
static electricity by touching a large for several seconds. Only Grounded Metal Surface
handle the by its edges and don’t touch the gold connectors.PCI Express Serial Card
Jumper Conguration
Note: Jumper Serial Devices conguration is a requirement when connecting that
require power through a . Serial Port
This can be moved into one of three dierent positions in order to set the Jumper
power output voltage for the . The default setting for the is , Serial Port Jumpers RI
which is the setting for no power. The can be moved to one of the other two Jumper
settings for or of power. To congure the , complete the following:5V 12V Jumper
1. Determine the power setting that is required for the .Serial Port
2. Locate the . The is labeled as on the .Jumper Jumper J1 Printed Circuit Board
3. Carefully remove the . Lift the straight up and o of the Jumper Jumper PCI Express
Serial Card.
Note: Always hold the by the edges.Card
4. Position the over the set of that correspond with the desired Jumper Pins Serial
Port Power Setting Jumper. See to determine where the Figure 1 should be
positioned.
5. Push the straight down and into place.Jumper
Note: Push the all the way into position for proper contact. Jumper
1
4
7
5
6
2
3
Probleemoplossing StarTech.com PEX1S953LP
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Groen |
| Gewicht: | 44 g |
| Breedte: | 67 mm |
| Diepte: | 98 mm |
| Hoogte: | 150 mm |
| Gewicht verpakking: | 112 g |
| Breedte verpakking: | 142 mm |
| Diepte verpakking: | 170 mm |
| Hoogte verpakking: | 30 mm |
| Gebruikershandleiding: | Ja |
| Soort serieële aansluiting: | RS-232 |
| Duurzaamheidscertificaten: | CE, RoHS |
| Aantal: | 1 |
| Temperatuur bij opslag: | -20 - 80 °C |
| Intern: | Ja |
| Naleving van duurzaamheid: | Ja |
| Ondersteunt Linux: | Ja |
| Mean time between failures (MTBF): | 277385 uur |
| Hostinterface: | PCIe |
| Datastroombeheer: | Ja |
| Ondersteunde server operating systems: | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016 |
| Montagebeugels meegeleverd: | Ja |
| Seriële poort(en): | 1 |
| Chipset: | Asix AX99100 |
| (Buitenste) hoofdverpakking hoogte: | 315 mm |
| (Buitenste) hoofdverpakking breedte: | 360 mm |
| (Buitenste) hoofdverpakking lengte: | 685 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 75 stuk(s) |
| Bedrijfstemperatuur (T-T): | 0 - 70 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 20 - 80 procent |
| Code geharmoniseerd systeem (HS): | 84733020 |
| Uitbreidingskaartstandaard: | PCIe 1.1 |
| FIFO (First In, First Out): | 256 B |
| Peripheral (Molex) power connectors (4-pin): | 1 |
| Output interface: | Serie |
| Baud snelheid: | 921.4 Kbit/s |
| Data bits: | 5, 6,7, 8,9 |
| Stop bits: | 1, 1.5, 2 |
| Parity bit: | Even, Mark, N,Odd, Space |
| Flow Control type: | N, RTS/CTS, XON/XOFF |
