Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: November 27, 2019 1:15 PM
Product Diagram (PEX2S953)
Port Function
1Serial Ports • Connect up to two Serial Devices
2Stand-os
• Attach the to the Bracket PCI Express Serial Card
• Secure the to the Serial Cables Serial Ports
3Bracket • Attach the to the PCI Express Serial Card Computer
4
PCI Express Bus
Connector
• Connect the to the PCI Express Serial Card
Computer Motherboard
5Jumper
• Congure the individual power Serial Connector
settings
6LP4 Power Connector • Used to connect an LP4 Power Source
2-Port PCI Express Serial Card with 16950 UART
Requirements
For the latest requirements please visit
www.startech.com/PEX2S953.
• PCIe Slot
• Needle-Nose Pliers
• (Optional) LP4 Power Source
Installation
WARNING! PCI Express Serial Cards can be severely damaged by static
electricity. Make sure that you are properly grounded before you open the
Computer Case PCI Express Serial Card or touch the . You should wear an
Anti-Static Strap Anti-Static when you install any computer component. If an
Strap isn’t available, discharge any built-up static electricity by touching a large
Grounded Metal Surface PCI Express Serial for several seconds. Only handle the
Card by its edges and don’t touch the gold connectors.
Jumper Conguration
Note: This is specially designed to allow for power output PCI Express Serial Card
from the ninth pin of the for that support power Serial Connector(s) Serial Devices
over serial. conguration is a requirement when connecting Jumper Serial Devices
that require power through a .Serial Connector
The can be moved into one of three dierent positions in order to set the Jumper
power output voltage for the . The default setting for the Serial Connector Jumpers
is , no power. The must be connected after conguring theRI LP4 Power Connector
Jumper 5V 12V Jumper to or of power. To congure the , complete the following:
1. Ensure the isComputer’s Power O.
2. Determine the power setting that is required for .Port One
3. Locate the for and carefully lift the straight up and o of Jumper Port One Jumper
the .PCI Express Serial Card
Notes: The Jumper for Port 1 is labeled as J1 on the Printed Circuit Board.
Always hold the Card by the edges.
4. Position the over the set of that correspond with the desired Jumper Pins Serial
Connector Power Setting Jumper. See to determine where the Figure 1 should be
positioned.
5. Push the straight down and into place.Jumper
Note: Push the all the way into position for proper contact. Jumper
1
4
6
1
5
2 2
3
5
