Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: January 6, 2021 9:41 AM
Product Diagram (RKCASTER2)
Component Function
1Casters x 4
• Roll a from location to Rack or Enclosure
location.
• stationary = 250 kg Maximum Weight Capacity
rolling = 75 kg.
2Mounting Holes x 4 • Securely mount the to a Casters Rack or
Enclosure.
Package Contents
• Casters x 4
• M6 Screws x 16 + (*2)
• Washers x 16 + (*2)
• M6 Nuts x 16 + (*2)
(* Spare Parts)
Requirements
For the latest requirements, please visit www.startech.com/RKCASTER2
• 10 mm Wrench x 2
• Rack or Enclosure w/ Caster Holes
Set of Four 45x75 mm M6 Casters
Installing the Casters
Racks or Enclosures with Caster Mounting Holes
Note: The must feature four sets of four Rack or Enclosure Caster Mounting
Holes.
1. Ensure the is positioned on it side.Rack or Enclosure
Note: Two people are required for repositioning the .Rack or Enclosure
2. Align the on the with the on Mounting Holes Casters Caster Mounting Holes
the bottom of the .Rack or Enclosure
3. Insert the (x 4) through the (x 4). M6 Screws Flat Washers
4. Insert the four through the M6 Screw and Flat Washer Combinations Caster
Mounting Holes Rack or Enclosure M6 Nut, the and into the .
Installing the Casters
5. While securing the in place with a , use a second M6 Nut 10 mm Wrench 10 mm
Wrench M6 Screwto tighten the .
6. Repeat step 5 to secure the other three .M6 Screws
Note: If the has adjust the Rack or Enclosure Leveling Feet, Leveling Feet
after the have been installed. Ensure the is level. Please Casters Rack or Enclosure
refer to the user manual for instructions on how to adjust the Rack or Enclosure’s
Leveling Feet.
7. Repeat steps 2-6 to install the three remaining . Casters
1
2
Probleemoplossing StarTech.com RKCASTER2
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Black, Stainless steel |
| Gewicht: | 2400 g |
| Breedte: | 65 mm |
| Diepte: | 92 mm |
| Hoogte: | 72.5 mm |
| Gewicht verpakking: | 2600 g |
| Breedte verpakking: | 225 mm |
| Diepte verpakking: | 125 mm |
| Hoogte verpakking: | 90 mm |
| Soort: | Zwenkwielen |
| Maximale gewichtscapaciteit: | 250 kg |
| Aantal per verpakking: | 4 stuk(s) |
| Compatibiliteit: | 4POSTRACK12U \tRK1224WALHM\n4POSTRACK25U \tRK1232WALHM\nRK1233BKM \tRK1520WALHM\nRK1833BKM \tRK2620WALHM\nRK2433BKM \tRK616WALM\nRK2537BKM \tRK9WALM\nRK4242BK24 \tRK4242BK30 |
| Inclusief schroeven: | Ja |
| (Buitenste) hoofdverpakking hoogte: | 390 mm |
| (Buitenste) hoofdverpakking breedte: | 410 mm |
| (Buitenste) hoofdverpakking lengte: | 245 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 12 stuk(s) |
| Code geharmoniseerd systeem (HS): | 85389099 |
| Sluitringen inbegrepen: | Ja |
| Inbegrepen sluitringen aantal: | 18 |
| Moeren inbegrepen: | Ja |
| Schroef-type: | 18 |
| Moeren aantal: | 18 |
