USB 3.0/eSATA Dual 3.5” SATA III Hard Drive External RAID Enclosure w/ UASP and Fan – Black
StarTech ID: S3520BU33ER
The S3520BU33ER 2-Bay RAID Enclosure offers a high-performance external storage solution, enabling you to
build a secure RAID array with two 3.5” SATA hard drives, with the option to connect it to your computer through
either an available USB 3.0 or eSATA port.
For fast data transfers and efficient performance from your SATA III drives, the RAID enclosure supports full
SATA III transfer speeds (up to 6 Gbps), as well as full USB 3.0 transfer speeds (up to 5Gbps). When connected
through USB, the enclosure supports UASP, which offers performance up to 70% faster than conventional USB
3.0 when paired with a UASP-enabled host controller (see our performance below).
With support for JBOD, Spanning, RAID 0, and RAID 1,the enclosure offers several options that enable you to
customize your drive arrangement based on your storage requirements.
To maximize both durability and reliability, the external RAID enclosure features high-quality aluminum
construction with a built-in fan that helps improve ventilation and maintain a better operating environment for
your drives.
The HDD enclosure offers a versatile solution for increasing the storage/backup capabilities of your computer,
with support for large capacity hard drives (tested up to 4TB).
To ensure compatibility with your computer system, the S3520BU33ER supports all of the leading operating
systems, including: Microsoft Windows® (8/7/Vista/XP/Server 2008/Server 2003), Apple® OSX
(10.9/10.8/10.7/10.6), Linux, and Google Chrome OS™.
It is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Improved Performance with UASP
UASP is supported in Windows 8, Mac OSX (10.8 or above), and Linux. In testing UASP performs with a 70%
faster read speed and 40% faster write speed over traditional USB 3.0 at peak performance.
www.startech.com
1 800 265 1844
Probleemoplossing StarTech.com S3520BU33ER
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 620 g |
| Breedte: | 113 mm |
| Diepte: | 176 mm |
| Hoogte: | 85 mm |
| Type stekker: | Type M |
| Gewicht verpakking: | 1400 g |
| Breedte verpakking: | 180 mm |
| Diepte verpakking: | 256 mm |
| Hoogte verpakking: | 140 mm |
| Gebruikershandleiding: | Ja |
| LED-indicatoren: | Activity, Power |
| AC-adapter ingangsspanning: | 100 - 240 V |
| USB-connectortype: | USB Type-B |
| Meegeleverde kabels: | SATA, eSATA |
| Certificering: | CE, FCC, REACH |
| USB-versie: | 3.2 Gen 1 (3.1 Gen 1) |
| Materiaal: | Aluminium, Plastic |
| Duurzaamheidscertificaten: | RoHS |
| Temperatuur bij opslag: | -20 - 50 °C |
| USB-aansluiting: | Ja |
| Aantal ventilatoren: | 1 ventilator(en) |
| AC-adapter, uitgangsspanning: | 12 V |
| AC-adapter, uitgangsstroom: | 3 A |
| Mean time between failures (MTBF): | 30000 uur |
| Opslag schijfgrootte: | 3.5 " |
| Maximale opslagcapaciteit: | 4 TB |
| Ondersteunde opslagstationinterfaces: | Serial ATA, Serial ATA II, Serial ATA III |
| Chipset: | JMicron - JMS562 |
| Soorten RAID: | 0, 1,BIG, JBOD |
| Overdrachtssnelheid: | 6 Gbit/s |
| Aantal storage drives ondersteund: | 2 |
| Aantal eSATA-poorten: | 1 |
| Bedrijfstemperatuur (T-T): | 5 - 35 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 20 - 80 procent |
| Type product: | HDD-behuizing |
| Hot-swap: | Ja |
| Ventilator diameter: | 80 mm |
| Geïntegreerde USB-kabel: | Nee |
| UASP-ondersteuning: | Ja |
| Poort-multiplier: | Ja |
