Manual Revision: 01/16/2015
For the most up-to-date information, please visit: www.startech.com
Quick Install Guide
Packaging Contents
• 1 x USB 3.0 to slimline SATA ODD enclosure
• 1 x USB 3.0 cable
• 1 x Quick start guide
System Requirements
• Computer system with available USB port
• 12.5mm Slimline SATA optical disc drive (ODD) (e.g. Blu-ray-RW,
DVD-RW, etc.)
SLSODDU33B
USB 3.0 to Slimline SATA Optical drive Enclosure
*actual product may vary from photos
Tool Requirements
• 1 x Phillips head screw driver
Installation
WARNING! ODD drives, media and enclosures require careful
handling, especially when being transported. If you are not careful
with your equipment damage may result. Always handle your hard
devices with caution. Be sure that you are properly grounded by
wearing an anti-static strap when handling computer components
or discharge yourself of any static electricity build-up by touching a
large grounded metal surface (such as the computer case) for several
seconds.
1. Using a Phillip’s head screw driver, remove the two ODD bay
access screws, from the back of the enclosure releasing the plastic
bezel.
2. Remove the plastic bezel and slide the drive tray from the front of
the enclosure.
3. Slide your slimline ODD into the drive tray from the front,
ensuring the SATA plug on your ODD is in line with the SATA
reciprocal on the back of the tray.
4. Ensure your ODD is rmly seated, then use your Phillip’s head
screw driver with the provided screws to secure the drive to the
tray using the mounting points on the side of the drive and tray.
5. Slide the assembled drive tray back into the enclosure housing.
6. Replace the plastic rear bezel and fasten using the previously
removed ODD bay access screws.
7. Using the included USB 3.0 cable, connect the enclosure to
an available USB port on the host computer system. No driver
software will install automatically once the operating system is
launched.
Product Overview
Front View
Rear View
ODD bay
USB 3.0
Micro B port
ODD bay
access screw
ODD bay
access screw
Probleemoplossing StarTech.com SLSODDU33B
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 277 g |
| Breedte: | 136 mm |
| Diepte: | 150 mm |
| Hoogte: | 20 mm |
| Gewicht verpakking: | 399 g |
| Breedte verpakking: | 208 mm |
| Diepte verpakking: | 151 mm |
| Hoogte verpakking: | 44 mm |
| Materiaal behuizing: | Aluminium, Plastic |
| Montage gereedschap: | Ja |
| USB-connectortype: | Mini-USB B |
| Type stroombron: | USB |
| Meegeleverde kabels: | USB |
| Snelstartgids: | Ja |
| Certificering: | CE, FCC |
| USB-versie: | 3.2 Gen 1 (3.1 Gen 1) |
| Duurzaamheidscertificaten: | RoHS |
| Plug and play: | Ja |
| Temperatuur bij opslag: | -20 - 70 °C |
| USB-aansluiting: | Ja |
| Maat: | 5.25 " |
| Max. overdrachtssnelheid: | 5 Gbit/s |
| Chipset: | Initio - 3619 |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 10 - 90 procent |
| Hot-swap: | Ja |
| Optical drive interface: | SATA |
| UASP-ondersteuning: | Nee |
