Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 09/01/2011

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1xVideoExtenderTransmitter

• 1xVideoExtenderReceiver

• 2xUniversalPowerAdapter

• 1xInstructionManual

System Requirements

• DVI-D/HDMIenabledvideosourcedevice(e.g.computer)

• DVI-D/HDMIenableddisplaydevice(e.g.monitor,projector)

• AvailableACelectricaloutletfortransmitterandreceiver

• DVI-D/HDMIcablefromreceivertodisplay

• DVI-D/HDMIcablefromvideosourcetotransmitter

• Cat6UTPEthernetcable(see“PreparingYourSite”)

ST121DVI25

ST121HD25

DVI Video Extender over Cat 6 UTP

High Speed HDMI® over Cat 6 UTP

Installation

1. Turnothevideosource(i.e.computer)andtheintendeddisplay

device(i.e.monitor).

2. PositiontheReceiverUnitneartheremotedisplay.

3. PositiontheTransmitterUnitnearthevideosource.

4. ConnectthevideosourcetotheDVI/HDMIportontherearpanel

oftheTransmitterUnit,usingamale/malecable.

5. ConnecttheremotedisplaytotheDVI/HDMIportlocatedonthe

rearpaneloftheReceiverUnitusingamale/malecable.

6. ConnecttheTransmitterUnittotheReceiverUnit,usingstandard

RJ45terminatedUTPCat6cable(see“PreparingYourSite”).

7. Connectthepoweradapters(provided)tobothTransmitterand

ReceiverUnits.

NOTE:BothunitscanalsobepoweredfromalocalUSBport,by

usingaUSBcable(soldseparately).Youmayalsoonlyconnect

powertotheTransmitterUnit,howevermaximumUTPcablelength

willbereducedto20m.

8. Turnonthedisplaydevicerst,followedbythevideosource.

Preparing Your Site

1. Determinewherethelocalvideosource(i.e.computer)willbe

locatedandsetupthedevice.

2. Determinewheretheremotedisplaywillbelocatedandplace/

mountthedisplayappropriately.

Please notethatbothextenderunitswillrequireapower

connection,sopleaseensurethateachunitwillbesituatednearan

availableACelectricaloutlet.

3. Ifyouareusingsurfacecabling,ensureyouhaveenoughCat6

unshieldedtwistedpair(UTP)Ethernetcablingtoconnectthe

LocalUnittotheRemoteUnit’slocation,andthateachendis

terminatedwithaRJ45Ethernetconnector.Thecablingshould

notgothroughanynetworkingequipment(i.e.router,switch).

Ifyouareusingpremisecabling,ensurethattheCat6unshielded

twistedpair(UTP)EthernetCablingbetweentheLocalUnitand

theRemoteUnithasbeenproperlyterminatedinawalloutlet/

panelineachlocationandthereisapatchcablelongenoughto

connecttheRemoteUnitandtheLocalUnittotheirrespective

outlets.Thecablingshouldnotgothroughanynetworking

equipment(i.e.router,switch).

Wiring Diagram

TheUTPcablemustbewiredaccordingtotheEIA/TIA568Bindustry

standardasshownbelow.

Pin Wire Color Pair

1White/Orange 2

2Orange

3 3White/Green

4Blue 1

5White/Blue

6 Green 3

7White/Brown 4

8Brown

*actual product may vary from photos

ST121DVI25

Probleemoplossing StarTech.com ST121DVI25

Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp

Specificaties

Kleur van het product:	Wit
Gewicht:	110 g
Gewicht verpakking:	500 g
Soort:	AV-zender & ontvanger
Gebruikershandleiding:	Ja
LED-indicatoren:	Stroom
Stroom:	1 A
Maximum resolutie:	1920 x 1080 Pixels
Aansluiting voor netstroomadapter:	Ja
Temperatuur bij opslag:	0 - 60 °C
Externe adapter:	Ja
DVI input ports:	1
DVI output ports:	1
RJ-45 uitgang ports:	1
Afmetingen (B x D x H):	55 x 80 x 23 mm
RJ-45 invoer ports:	1
Operating voltage:	5 V
Maximaal bereik:	25 m
Bedrijfstemperatuur (T-T):	0 - 40 °C
Relatieve vochtigheid in bedrijf (V-V):	20 - 90 procent
Ondersteundende kabel types:	Cat6
