Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 10/16/2014
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 1x HDMI Audio/Video Splitter (ST122HD4KU)
• 1x Power Adapter (NA/EU/UK/AUS)
• 1x USB power Cable
• 1x Instruction Manual
System Requirements
• 1x HDMI-enabled Video Source Device (i.e. Blu-ray player,
computer, etc.)
• 2x HDMI-enabled Display Devices w/ cabling (i.e. Television,
projector, etc.)
Product Diagram
Front View
Hardware Installation
Note: Ensure your HDMI-enabled video source device, and the
HDMI-enabled Display Devices are powered o before you begin
installation.
1. Connect the on the HDMI Input Dongle Cable ST122HD4KU
from the A/V output port of your HDMI-enabled Video Source
Device.
2. Connect an (not included) from each of theHDMI cable HDMI
output ports ST122HD4KU HDMI input port on the to the on
your HDMI-enabled Display Devices.
Note: Each port is numbered, please take note of which number is
assigned to each HDMI-enabled display device.
3. Power on each HDMI-enabled Display Device, followed by your
HDMI-enabled Video Source Device.
4. Connect the included power adapter from an available power
source to the power adapter port ST122HD4KU. on the
Or
If you would prefer to use a USB power source, connect the
included from an available USB power source, USB power cable
to the power adapter port ST122HD4KU. on the
5. Your Video source device A/V output will now appear on each
attached HDMI-enabled display device.
ST122HD4KU
2-Port HDMI® Splitter with USB Power – 4K
HDMI Output Port 1
HDMI Output Port 1
Activity LED
HDMI Input Dongle
Cable
HDMI Output Port 2
Activity LED
HDMI Output Port 2
Power Adapter Port
Rear View
Activity LED
Each HDMI output port on the ST122HD4KU is equipped with an
Activity LED. This LED will light while an active HDMI display is
attached and receiving a video input signal.
Probleemoplossing StarTech.com ST122HD4KU
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 235 g |
| Breedte: | 50 mm |
| Diepte: | 620 mm |
| Hoogte: | 18 mm |
| Gewicht verpakking: | 396 g |
| Breedte verpakking: | 230 mm |
| Diepte verpakking: | 156 mm |
| Hoogte verpakking: | 56 mm |
| Gebruikershandleiding: | Ja |
| Stroom: | 0.5 A |
| Ethernet LAN: | Nee |
| Maximum resolutie: | 3840 x 2160 Pixels |
| Meegeleverde kabels: | USB |
| Inclusief AC-adapter: | Ja |
| Certificering: | REACH, FCC, CE |
| Volledige HD: | Ja |
| Maximale refresh snelheid: | 30 Hz |
| Aansluiting voor netstroomadapter: | Ja |
| HDMI versie: | 1.4 |
| Ondersteunde grafische resoluties: | 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1600 (WQXGA) |
| Duurzaamheidscertificaten: | RoHS |
| Output current: | 2 A |
| Spanning: | 5 V |
| Stroomvoorziening via USB: | Ja |
| Video uit: | 2x HDMI |
| Aansluiting video: | HDMI |
| AC-ingangsspanning: | 100-240 V |
| Code geharmoniseerd systeem (HS): | 85176990 |
| Inbegrepen soorten voedingsstekkers: | AU, EU, NA, UK |
| Hoeveelheid Video ports: | 2 |
| Audio support: | Ja |
