2/ 4/ 8 Port VGA Video Splitter - Wall Mountable
ST122W / ST124W / ST128W
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l’utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l’uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Features
• Max.supportedresolutionsupto1600x1200
• Cascadableupto3levels
• Supportstransmissiondistancesupto65m/200’
SystemRequirements
• AcomputerwithaVGACardinstalled
• DE-15VGAmale/femalevideocable
• DE-15VGAmale/malevideocable(s)
Installation
InaSingleUnitInstallation,onlyonevideosplitterisused,inturn
limitingthenumberofdisplaystowhichthesplitsignalcanbe
broadcast;aCascadedcongurationontheotherhand,utilizes
multiplesplittersconnectedtooneanothertoprovidingnumerous
additionalvideoconnections(i.e.ST122Wcanbecascadedto
provideupto8videooutputs,ST124Wupto64andST128Wup
to512.
Single Unit Installation
1.Withthevideosourcecomputerpowereddown,useahigh
densityDE-15male/femaleVGAcabletoconnectthecomputer
VideoOutporttotheVideoINportonthesplitter.
2.UsingahighdensityDE-15male/maleVGAcableforeach
connection,connectthemonitorstotheVideoOUTports
providedbythesplitter.
3.ConnectthePowerPortonthevideosplittertoanavailable
poweroutlet,usingtheprovidedadapter.
4.Powerupthesourcecomputerandnewlyconnectedmonitors.
Cascaded Installation
Tocascademultiplesplitters,useahighdensityDE-15male/female
VGAcabletoconnectanyavailableVideoOUTportonthe“higher
level”videosplittertotheVideoINportofthelowerlevelvideo
splitter.Youcancascadeasmanyvideosplittersasthereareports
available,howeverthesignalwilldeteriorateasdistancebetween
themonitorandsourceincreases.
Pleaseseereverseforadiagramdepictingacascaded
conguration.
TopView(ST124Wshown)
RearView(ST124Wshown)
PowerIndicator
VideoINport
VideoOUTports
PowerPort
Instruction Manual
*actual product may vary from photos
ManualRevision:02/01/2012
For the most up-to-date information, please visit: www.startech.com

Probleemoplossing StarTech.com ST128W

Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp

Specificaties

Aansluiting(en): 8 - DB15 F, 1 - DB15 M
Maximale afstand: 65 m
Video uit: 8x VGA
Bandbreedte: 200 MHz
Aansluiting video: VGA
Hoeveelheid Video ports: 8
