Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: December 9, 2019
Product Diagram (SV211HDUA4K)
Component Function
1Stereo Audio Connector
• Connect the from the Speaker Audio
Computer
2USB-A Connector
• Transmit the signal of a and Keyboard Mouse
from the to the KVM Switch Computer
3
Microphone Audio
Connector
• Connect the to the Microphone Audio
Computer
4Microphone Audio Port • Connect a Microphone
5USB HID Ports
• Connect a and Keyboard Mouse
• (Optional) Connect USB Peripherals
6HDMI Port • Connect a HDMI Display
7HDMI Connector • Connect a HDMI Enabled Computer
2-Port USB HDMI® Cable KVM Switch w/ Audio and Remote Switch - 4K 60Hz
8LED Indicators • Indicates selection and activityComputer
9Stereo Audio Port • Connect Stereo Speakers
10 Remote Switch
• A wired button used to switch between
Computer 1 2 and
• Press Release Remote Switch and the to
switch between and Computer 1 2
Requirements
• HDMI Enabled Computers x 2
• HDMI Display x 1
• USB HID Devices (Keyboard and Mouse) x 2
• (Optional) USB Peripherals x 2
• (Optional) Microphone x 1
• (Optional) Stereo Speakers or Headphones x1
• (Optional) Headset x 1
Note: A Headset may require the use of a Headset Adapter. Check with the
manufacturer of the Headset for more details.
• (Optional) 3.5 mm Audio Cables x 2
For the latest requirements and to view the full User Manual, please visit
www.startech.com/SV211HDUA4K.
Installation
Connect the Computers
1. Connect the built-in to the on Computer 1 HDMI Connector HDMI Port
Computer 1.
2. Connect the built-in to the on Computer 1 USB-A Connector USB-A Port
Computer 1.
3. (Optional) Connect the built-in (green) to the Computer 1 Stereo Audio Connector
3.5 mm Stereo Audio Port Computer 1 on .
4. (Optional) Connect the built-in (pink) Computer 1 Microphone Audio Connector
to the on .3.5 mm Microphone Audio Port Computer 1
5. Repeat steps 1-4 to install .Computer 2
Connect the Console
1. Connect the to the USB-A Devices (Keyboard, Mouse, or USB Peripherals) USB-A
Ports KVM Switch Keyboard Mouse USB Cables on the using the built-in and or
USB-A Cables (sold separately).
7
1
2
3
5
6
5
9
10
8
4
