Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
JP: - jp.startech.com取扱説明書
Manual Revision: 03/28/2018
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/SV431DHD4KU.
Package contents
• 1 x KVM switch
• 1 x universal power adapter (NA/JP, EU, UK, ANZ)
• 4 x rubber feet
• 1 x quick-start guide
Requirements
• HDMI cables
• USB-A to USB-B or USB-C to USB-B cables
• 3.5 mm audio cables
• Computer system or video card enabled with HDMI
• Computer system enabled with USB
• Display device (for example, monitor, projector, TV, and so on)
enabled with HDMI
• Standard USB keyboard and mouse (wired or wireless)
Requirements are subject to change. For the latest requirements,
please visit www.StarTech.com/SV431DHD4KU.
SV431DHD4KU
4-Port Dual HDMI KVM Switch - 4K 30Hz
*actual product may vary from photos
Product diagram
Front view
Port selection/link LEDs Power LED
Port selection
buttons
Back view
Power
adapter
port
PC USB
port
USB HID
ports
PC HDMI
ports
USB
hub
port
Installation
Connect the console to the KVM switch
1. Turn o your computer and any devices or peripherals that are
connected to it (for example, printers, external hard drives, and so
on).
2. Connect two monitors or displays to the Console HDMI ports.
3. Do one of the following:
• Connect a keyboard and a mouse to two of the USB HID
ports.
• If you’re using a combination wireless keyboard and mouse,
connect the wireless receiver one of the USB HID ports.
4. If necessary, do any of the following:
• Connect speakers to the Console audio port.
• Connect USB peripherals to the USB hub ports.
• Connect additional HID devices (touchpads, touchscreens,
number pads, etc.) to available HID ports.
Connect a computer to the KVM switch
Notes:
• No software or driver installation is required.
• The cables for each individual computer must be connected to the
same port set on the KVM switch.
1. Turn o the computers that you want to connect to the KVM
switch and any devices or peripherals that are connected to the
computers (e.g. printers, external hard drives, etc.)
2. Connect an HDMI video cable to each of the HDMI ports on your
computer and to the PC HDMI ports of the same set, on the KVM
switch.
3. Connect a USB cable to the USB port on your computer and to the
PC USB port on the KVM switch.
4. Optional: Connect an audio cable to the audio output on your
computer and the PC audio port on the KVM switch.
5. To connect additional computers, repeat steps 1 to 4.
PC audio
port
Console
HDMI ports
Console
audio port
USB HID
port USB hub
port
USB hub
port
EDID copy
buttons
Probleemoplossing StarTech.com SV431DHD4KU
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Ingebouwd display: | Nee |
| Gewicht: | 1200 g |
| Breedte: | 130 mm |
| Diepte: | 220 mm |
| Hoogte: | 63 mm |
| Gewicht verpakking: | 1800 g |
| Breedte verpakking: | 124 mm |
| Diepte verpakking: | 295 mm |
| Hoogte verpakking: | 85 mm |
| Materiaal behuizing: | Staal |
| Stroombron: | AC |
| LED-indicatoren: | Power, Status |
| Stroom: | 0.6 A |
| USB-connectortype: | USB Type-A |
| Maximum resolutie: | 3840 x 2160 Pixels |
| Aantal HDMI-poorten: | 10 |
| Hoofdtelefoonuitgangen: | 4 |
| Certificering: | CE, FCC, TAA, REACH |
| HD type: | 4K Ultra HD |
| Duurzaamheidscertificaten: | RoHS |
| Temperatuur bij opslag: | -10 - 60 °C |
| Sneltoetsen: | Ja |
| Externe adapter: | Ja |
| Rack-montage: | Ja |
| Output current: | 1.5 A |
| Spanning: | 12 V |
| Snelle installatiehandleiding: | Ja |
| Mean time between failures (MTBF): | 168000 uur |
| Rubberen voetjes: | Ja |
| Aansluiting video: | HDMI |
| AC-ingangsspanning: | 100 - 240 V |
| Stroomverbruik (typisch): | 18 W |
| Bedrijfstemperatuur (T-T): | 0 - 40 °C |
| Relatieve vochtigheid in bedrijf (V-V): | 0 - 80 procent |
| Code geharmoniseerd systeem (HS): | 85176200 |
| Aansluiting toetsenbord: | USB |
| Aansluiting muis: | USB |
| Aantal computers: | 4 |
| Console-poorten: | 3.5mm headphone, HDMI, USB A |
| Compatibele soorten stopcontacten: | AU, EU, JP, UK, US |
| Data transfer snelheid (max): | 5 Gbit/s |
| Scaninterval: | 3, 8,15, 30 s |
| Aantal USB-poorten console: | 6 |
| IP control: | Nee |
