Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
Manual Revision: 08/04/2016
For the latest information, technical specications, and support for
this product, please visit www.startech.com/TBT3TBTADAP.
Package contents
• 1 x Thunderbolt™ 3 to Thunderbolt adapter
System requirements
• Host desktop computer or laptop with a Thunderbolt 3 port
• Thunderbolt or Thunderbolt 2 device
• Thunderbolt cable
System requirements are subject to change. For the latest
requirements, please visit www.startech.com/TBT3TBTADAP.
TBT3TBTADAP
Thunderbolt™ 3 to Thunderbolt Adapter
*actual product may vary from photos
Introduction
Use the TBT3TBTADAP adapter to connect a Thunderbolt 3 desktop
or laptop computer to legacy Thunderbolt devices, including
external hard drives, Thunderbolt displays, and Mac computers that
are Thunderbolt capable. The TBT3TBTADAP is compatible with rst-
generation Thunderbolt and Thunderbolt 2 devices, making it a cost-
eective method to connect newer devices to older peripherals.
You can use the TBT3TBTADAP to connect to rst-generation
Thunderbolt devices at 10Gbps and Thunderbolt 2 devices at
20Gbps.
Product diagram
Thunderbolt 3 USB-C connector
Thunderbolt 2 port
Connect the Thunderbolt adapter
Your computer’s Thunderbolt 3 ports might not function properly
until you update one or more of the following on your computer:
• BIOS
• Thunderbolt rmware
• Thunderbolt 3 controller drivers
• Thunderbolt 3 software
The required updates will vary depending on your computer.
For an up-to-date list of aected computers and instructions, visit
http://thunderbolttechnology.net/updates. If your manufacturer
isn’t listed on the Thunderbolt website, contact your manufacturer.
Make sure that the Thunderbolt device that you’re using with the
TBT3TBTADAP is compatible with the OS that you’re running on your
computer.
1. Connect the connector to the Thunderbolt 3 USB-C Thunderbolt
3 USB-C port on your desktop or laptop.
2. Use a Thunderbolt cable to connect the Thunderbolt device to the
Thunderbolt 2 port on the Thunderbolt adapter.
3. If you’re using a Windows® operating system, a pop-up message
may appear requesting permission to allow the adapter to
connect to your computer. If this message appears, click > . OK Yes
In the drop-down list, select Connect always OK and click .
The following is an example of a setup that includes the Thunderbolt
adapter:
Probleemoplossing StarTech.com TBT3TBTADAP
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht: | 58 g |
| Snoerlengte: | 0.2 m |
| Gewicht verpakking: | 86 g |
| Breedte verpakking: | 82 mm |
| Diepte verpakking: | 178 mm |
| Hoogte verpakking: | 25 mm |
| Certificering: | CE, FCC, Thunderbolt, REACH |
| Duurzaamheidscertificaten: | RoHS |
| Aantal per verpakking: | 1 stuk(s) |
| Compatibele besturingssystemen: | Windows 8.1, 10, 11\nmacOS 10.12 - 10.15, 11.0, 12.0, 13.0 |
| Contact geleider materiaal: | Nikkel |
| (Buitenste) hoofdverpakking hoogte: | 296 mm |
| (Buitenste) hoofdverpakking breedte: | 309 mm |
| (Buitenste) hoofdverpakking lengte: | 375 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 72 stuk(s) |
| Code geharmoniseerd systeem (HS): | 84733080 |
| Aansluiting 1: | Vrouw |
| Aansluiting 2: | Man |
| Data transfer snelheid (max): | 20 Gbit/s |
| Materiaal buitenmantel: | Polyvinyl chloride (PVC) |
| Kabelafscherming: | Aluminium mylar-folie |
