Universal Intel P4/AMD Athlon
Heatsink and Fan
UNIVERSALHSF
Thank you for purchasing a Universal Intel
P4/AMD Athlon heatsink with fan.
Designed to fit a wide range of Intel and
AMD processors, this extra-large heat sink
and 7cm ball bearing fan provides maximum
heat dissipation for your hard-working
CPU. The UV-reactive fan looks great in
modded cases and offers 27.9 CFM of
airflow.
The UNIVERSALHSF is designed
for the following processors:
• Intel P4 3.2 GHz
• Intel PIII
• AMD Athlon XP 3000+
• AMD K7 and K8
Note: For maximum efficiency, use the included thermal compound with your
UNIVERSALHSF.
Warning! Remove the protective plastic cover from the bottom
of the heatsink before installation.
Technical Specifications
AMD K8 (Athlon 64)
1. Release the screws from the
plastic plates on the bottom of the
heatsink and remove the plates.
2. Attach the diamond-shaped plastic
plate to the bottom of the
motherboard.
3. Fasten the other plastic retention
plate to your motherboard using
screws.
4. Hook the clip to the retention
plate from one side.
5. Connect the power wire to a
power source on your
motherboard.
6. Installation is now complete.
The Professionals’ Source For Hard-to-Find Computer Parts
Processor Compatibility Intel P4 3.2GHz (Socket 478), Intel PIII (Socket 70),
AMD Athlon XP 3000+, AMD Athlon K8,
AMD Athlon K7 (Socket 462)
Heatsink Dimensions 3.3 x 2.9 x 1.7” (84 x 74 x 42 mm)
Fan Dimensions 70 x 70 x 15 mm
Fan Speed 3500 RPM
Power Consumption 2.1 Watts (0.18A)
Airflow 27.9 CFM
Noise 28 dBA
Weight 0.71 lbs (0.32 kg.)
Safety Standard CE
Probleemoplossing StarTech.com UNIVERSALHSF
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Blauw |
| Gewicht: | 363 g |
| Soort: | Luchtkoeler |
| Geluidsniveau (hoge snelheid: | 28 dB |
| Compatibele producten: | Intel P4 3.2 GHz\nIntel PIII\nAMD Athlon XP 3000+\nAMD K7 & K8 |
| Aansluiting(en): | 1 - TX3 Female |
| Rotatiesnelheid: | 3500 RPM |
| Afmetingen (B x D x H): | 75 x 102 x 71 mm |
| Bearing technologie: | Kogellager |
| Luchtcirculatie: | 27.9 CFM |
