StarTech.com USB2002EXT2NA Handleiding
Hier is de StarTech.com USB2002EXT2NA (Not categorized) gebruikershandleiding. 2 pagina's in taal Engels met een gewicht van 0.4 Mb. Als u geen antwoorden op uw probleem kunt vinden Vraag het onze community.
Pagina 1/2
Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: April 28, 2020 8:30 AM
Product Diagram (USB2002EXT2NA)
Front
Rear
Component Function
1USB-A Ports • Used to connect (mouse, keyboard, USB Devices
etc.) to the .Remote Extender
2 Port USB 2.0 Extender over Cat5e, Cat6, or Cat7 | Locally or Remotely Powered | Up to 330 ft (100 m)
2LEDs (Local/Remote)
Power:
• Solid Blue: Extenders The are receiving power.
Link:
• Solid Green: Extenders The are linked.
• O: Extenders The are not linked.
Host:
• Solid: Extender Host Computer is linked to the .
• Flashing: Extenders are in suspend mode.
Activity:
• Flashing: Extenders Data is transmitted between .
• O: Extenders are in a suspended mode.
3Mode Button • Used for rmware management/updates.
4Cong Port • Used for rmware management/updates.
5Power Port 24V 1A
(Local/Remote)
• Used to connect the and Local Remote Extender
to using theAC Electrical Outlets, Power Adapter
(included).
6RJ45 Port - Link (Local/
Remote)
• Used to connect the to the Local Extender Remote
Extender.
• Max. data transfer rate = 480Mbps
7USB-B Host Port • Used to connect the to a Local Extender Host
Computer USB Cable, using the (included).
Requirements
For the latest requirements, please visit www.startech.com/USB2002EXT2NA
• USB Enabled Host Computer
• Solid Core Cat5e unshielded twisted pair (UTP) or greater
Installation
1. Position the near the and an .Local Extender Host Computer AC Electrical Outlet
2. Position the near an .Remote Extender AC Electrical Outlet
123
5 6 7
4
Probleemoplossing StarTech.com USB2002EXT2NA
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Plug and play: | Y |
| Output current: | 1 A |
| Output voltage: | 24 V |
| Type: | Console transmitter & receiver |
| Product colour: | Black |
| Width: | 76 mm |
| Depth: | 87 mm |
| Height: | 26 mm |
| Weight: | 289 g |
| Package weight: | 840 g |
| Power consumption (typical): | 24 W |
| Quick start guide: | Y |
| Cables included: | AC, USB |
| Package width: | 196 mm |
| Package height: | 77.5 mm |
| Package depth: | 243 mm |
| Sustainability certificates: | RoHS |
| Certification: | CE, FCC, REACH |
| Power plug type: | Type M |
| DC-in jack: | Y |
| Products per master (outer) case: | 14 pc(s) |
| Master (outer) case height: | 270 mm |
| Master (outer) case width: | 406 mm |
| Master (outer) case length: | 558 mm |
| Housing material: | Aluminium, Plastic |
| Cable types supported: | Cat5e, Cat6, Cat7 |
| Operating temperature (T-T): | 0 - 50 °C |
| Operating relative humidity (H-H): | 10 - 90 % |
| AC adapter included: | Y |
| Input voltage: | 100 - 240 V |
| Storage temperature (T-T): | -20 - 70 °C |
| Data transfer rate: | 480 Mbit/s |
| Input current: | 0.6 A |
| Maximum transfer distance: | 100 m |
| USB 2.0 Type-A ports quantity: | 2 |
| USB 2.0 Type-B ports quantity: | 1 |
| RJ-45 ports quantity: | 2 |
| Mounting kit: | Y |
