Pagina 1/43
Manual Is Applicable To The Following Models*
GMGX4, GMG4, GMG6, GMG8, GMG8.6552,
GMG12, GVGV4, GMGV8 and GMGV12
*Note: This manual may also be applicable
to models NOT listed herein.
FUSION GMG GRAVITY & BLOWER COIL MEAT & SEAFOOD REFRIGERATED SERVICE UNITS
REV N DATE: 7/6/2023
USER MANUALS\5-4467_FUSION_USER MANUAL_GMG_GRAVITY COIL_MEAT-SEAFOOD_CASE
Model GMG4 Seafood Case: Remote
Unit ||| Rear Sliding Doors Removed.
Ice Pans Used (Instead of Wire
Racks as used in Meat Case Models
GMG6, GMG8 and GMG12)
Model GMG12 Meat Case: Remote Unit / Rear Sliding
Doors Removed. Wire Racks Used (Instead of Ice Pans
As Used in Seafood Model GMG4)
Model GMG12 Hybrid Unit Meat Case: Remote Unit / Gravity Coil (Upper),
Evaporator Coil (Lower) and Shelf / Rear Sliding Doors Removed. Wire
Racks Used (Instead of Ice Pans as used in Seafood Model GMG4)
Model GMG6 Meat Case:
Self-Contained Unit ||| Rear
Sliding Doors Intact / Wire
Racks Used (Instead of Ice
Pans Used In Meat
Case Models GMG4)
Model GMGX4 Blower Coil
Wedge Case: Remote Unit /
Single Rear Hinged Door / Ice
Pans Used (Instead of Wire
Racks as used in Meat Case
Models GMG6, GMG8
and GMG12)
Model GMGV12: Remote Service Unit / Mid-Volume Angled Back
With Gravity Coil and Vertical “Lift-Up” Front Glass / Rear Sliding
Doors (Shown Removed) / Ice Pans Used (Instead of Wire Racks
as used in Meat Case) / Optional Paper Roller
Model GMG4.6552: Remote Unit
Mid-Volume Angled Back Deli Case
With Gravity Coil and Scale Stand
Model GMGV4
Blower Coil Case:
Self-Contained
Unit / Wire Racks
SCC P/N
5-4467
USER
MANUAL
FUSION
CAREFULLY FOLLOW THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 ∙ www.structuralconcepts.com
