Pagina 1/15
EN 1
English
Important information
Safety
Ensure that your domestic mains supply voltage
matches the voltage indicated on the identication
sticker located at the back of your set. Where the
mains plug, AC inlet or an appliance coupler is used
as disconnect device, it shall remain readily operable.
On certain models, the light indicator is located at the
side of the TV set. The absence of a light indication
at the front does not mean that the TV set is fully
disconnected from the mains. To disconnect the TV
set completely, the mains plug must be pulled out.
The TV set’s components are sensitive to heat. The
maximum ambient temperature should not exceed
35º Celsius. Do not cover the vents at the back or
sides of the TV set. Leave sufcient space around it to
allow adequate ventilation. Install the appliance away
from any source of heat (replace, etc.) or appliances
creating strong magnetic or electric elds.
Moisture in rooms where the set is installed should
not exceed 75% humidity. Moving the set from a cold
place to a warm one can cause condensation on the
screen (and on some components inside the TV set).
Let the condensation evaporate before switching the
TV set on again.
The or POWER/ button on the TV set or the
button on the remote control can be used to switch it
on and put it into standby mode. If you are not going
to be watching the TV for a lengthy period of time ,
switch it off completely by removing the plug from the
mains power socket.
During thunderstorms, we recommend that you
disconnect the TV set from the mains and aerial so
that it is not affected by electrical or electromagnetic
surges that could damage it. For this reason, keep the
mains and aerial sockets accessible so they can be
disconnected, if necessary.
Unplug the TV set immediately if you notice it giving
off a smell of burning or smoke. You must never,
under any circumstances, open the TV set yourself,
as you run the risk of an electric shock in doing so.
WARNINGS
This appliance is intended for domestic household
use only and should not be used for any other
application, such as for non-domestic use or in a
commercial environment.
If the external exible cable or cord of this product is
damaged, it shall be replaced by the manufacturer or
his service agent or a similar qualied person in order
to avoid a hazard.
Leave more than 10cm clearance around the
television to allow adequate ventilation. The
ventilation should not be impeded by covering the
ventilation openings with items, such as newspapers,
table-cloths, curtains, etc.
The apparatus shall not be exposed to dripping or
splashing and no objects lled with liquids, such as
vases shall be placed on the apparatus.
Batteries (battery pack or batteries installed) shall not
be exposed to excessive heat such as sunshine, re
or the like.
To reduce the risk of re or electric shock, do not
expose this apparatus to rain or moisture.
A television set may fall, causing serious personal
injury or death. Many injuries, particularly to children,
can be avoided by taking simple precautions such as:
• ALWAYS use cabinets or stands or mounting
methods recommended by the manufacturer of the
television set.
• ALWAYS use furniture that can safely support the
television set.
• ALWAYS ensure the television set is not
overhanging the edge of the supporting furniture.
• ALWAYS educate children about the dangers of
climbing on furniture to reach the television set or its
controls.
• ALWAYS route cords and cables connected to your
television so they cannot be tripped over, pulled or
grabbed.
• NEVER place a television set in an unstable
location.
• NEVER place the television set on tall furniture
(for example, cupboards or bookcases) without
anchoring both the furniture and the television set to
a suitable support.
• NEVER place the television set on cloth or other
materials that may be located between the television
set and supporting furniture.
• NEVER place items that might tempt children to
climb, such as toys and remote controls, on the top
of the television or furniture on which the television
is placed.
If the existing television set is going to be retained
and relocated, the same considerations as above
should be applied.
Equipment with this symbol is a Class II or
double insulated electrical appliance. It has
been designed in such a way that it does
not require a safety connection to electrical
earth.
Equipment without this symbol is a Class I
electrical appliance. It shall be connected
to a mains socket outlet with a protective
earthing connection.
To prevent the spread of re, keep candles
or other open ames away from this product
at all times.
Probleemoplossing TCL 32S5200
Als je de handleiding al zorgvuldig hebt gelezen maar geen oplossing voor je probleem hebt gevonden, vraag dan andere gebruikers om hulp
Specificaties
| Kleur van het product: | Zwart |
| Gewicht verpakking: | 5300 g |
| Breedte verpakking: | 800 mm |
| Diepte verpakking: | 126 mm |
| Hoogte verpakking: | 512 mm |
| Bluetooth: | Ja |
| Omgevingslichtsensor: | Nee |
| Type verpakking: | Doos |
| Automatisch uitschakelen: | Ja |
| Montage gereedschap: | Nee |
| Afstandsbediening: | RC802NU1 |
| Aantal processorkernen: | 4 |
| Wi-Fi-standaarden: | 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Bluetooth-versie: | 5.0 |
| Bluetooth-profielen: | A2DP, HID |
| Ondersteund audioformaat: | WMA, MP3 |
| Ondersteunde videoformaten: | AVI, WMV, MP4, MPG, TS, MKV, OGM |
| Ethernet LAN: | Ja |
| Kijkhoek, horizontaal: | - ° |
| Kijkhoek, verticaal: | - ° |
| Meegeleverde kabels: | AC |
| Geïntegreerde geheugenkaartlezer: | Nee |
| Kleurnaam: | Zwart |
| Land van herkomst: | Polen |
| Pakketgewicht: | 5.3 kg |
| Aantal USB 2.0-poorten: | 1 |
| Aantal HDMI-poorten: | 2 |
| Componentingang video (YPbPr/YCbCr): | 1 |
| DVI-poort: | Nee |
| Aantal Ethernet LAN (RJ-45)-poorten: | 1 |
| Stroomverbruik (in standby): | 0.38 W |
| Ondersteund aantal accu's/batterijen: | 2 |
| Vermogensverbruik (max): | 50 W |
| Hoofdtelefoonuitgangen: | 1 |
| Certificering: | CE |
| HDCP: | Ja |
| Smartphone ondersteuning op afstand: | Ja |
| High Dynamic Range (HDR)-technologie: | High Dynamic Range 10 (HDR10) |
| HDR-ondersteuning: | Ja |
| Ingang stroom: | Ja |
| Ondersteund beeldformaat: | BMP, JPG, PNG |
| HDMI versie: | 1.4 |
| VESA-montage: | Ja |
| Paneelmontage-interface: | 100 x 100 mm |
| Antireflectiescherm: | Nee |
| Picture-in-Picture: | Nee |
| Ingebouwde camera: | Nee |
| Diepte ( zonder voet ): | 80 mm |
| Hoogte (zonder voet ): | 435 mm |
| Breedte ( zonder voet ): | 732 mm |
| Gewicht (zonder voet): | 3900 g |
| Schermdiameter in centimeters: | 81.3 cm |
| Digitale audio, optische uitgang: | 1 |
| Common interface Plus (CI+): | Ja |
| Versie Common Interface Plus (CI+): | 1.3 |
| Timeshift: | Nee |
| Apple AirPlay 2-ondersteuning: | Nee |
| Werkt met Amazon Alexa: | Ja |
| Ingebouwde audio decoders: | Dolby Digital |
| Enhanced Audio Return Channel (eARC): | Nee |
| Energieverbruik (HDR) per 1000 uur: | 42 kWu |
| Energie-efficiëntieklasse (SDR): | F |
| Energieverbruik (SDR) per 1000 uur: | 32 kWu |
| Energie-efficiëntieklasse (HDR): | G |
| Miracast: | Ja |
| Webbrowser: | Ja |
| Oprolbaar scherm: | Nee |
| Breedte apparaat (met standaard): | 732 mm |
| Diepte apparaat (met standaard): | 175 mm |
| Hoogte apparaat (met standaard): | 480 mm |
| Gewicht (met standaard): | 4000 g |
| Bureaustandaard: | Ja |
| Local dimming: | Nee |
| Ruisonderdrukking: | Ja |
| AMD FreeSync: | Nee |
| 4K Ultra HD upscaler: | Nee |
| Beeldverwerkingstechnologie: | TCL Pure Image Ultra |
| Ingebouwde subwoofer: | Nee |
| Verhouding maximale helderheid: | 78 procent |
| Kwikgehalte: | 0 mg |
| Teletext: | Ja |
| Browsen: | Ja |
| Equalizer-instellingen: | Ja |
| Automatische volumeregelaar: | Ja |
| Aan/uit-timer: | Ja |
| Elektronische TV-gids: | Ja |
| On Screen Display (OSD): | Ja |
| Aantal On Screen Display-talen: | 39 |
| Audio Return Channel (ARC): | Ja |
| Consumer Electronics Control (CEC): | T-link |
| Common interface (CI): | Ja |
| Aantal RF-poorten: | 2 |
| Systeemeigen vernieuwingsfrequentie: | 60 Hz |
| Lifestyle-apps: | Google Apps |
| Technologie voor decoderen van geluid: | Dolby Digital Plus |
| Bevat geen: | Kwik |
| Intel® Wireless Display (Intel® WiDi): | Nee |
| Mobile High-Definition Link ( MHL ): | Nee |
| Game modus: | Ja |
| Smart modes: | Game, Movie, Sports |
| LED backlight-type: | Direct-LED |
| Teletekst: | - pagina's |
| Ondertitelingsfunctie: | Ja |
| Video on Demand (VOD) ondersteuning: | Ja |
| Programmeringsperiode: | 8 dag(en) |
| Hotel-modus: | Ja |
| Upgraden van firmware mogelijk: | Ja |
| Firmware kan geüpgraded worden via: | Network, USB |
| Aantal tuners: | 1 tuner(s) |
| Gemiddeld vermogen subwoofer: | - W |
| Horizontaal draaibaar: | - ° |
| USB-klonen: | Ja |
| Ondersteunde verversingsfrequenties display: | 60 Hz |
| Grootte beeld (diagonaal): | 800 mm |
| Soundbar inbegrepen: | Nee |
| Batterijen: | 2 |
| Basis-hotelmodus: | Ja |
| Screen mirroring: | Ja |
| Progressive scan: | Ja |
| Gewicht batterij: | 15 g |
| Marketingnaam dynamische contrastratio: | Mega Contrast |
| Adaptief geluid: | Ja |
| Omgevingsverlichting: | Nee |
| RF aansluitingstype: | F, IEC |
| Componentuitgang video (YPbPr/YCbCr): | 1 |
| Ouderlijk toezicht: | Ja |
| Stapelbaar: | Ja |
| DVD player: | Nee |
| Aantal kanalen: | - kanalen |
| Soundbar speaker RMS vermogen: | - W |
| Meegeleverde subwoofer: | Nee |
| Draaibare display: | Nee |
| Werkt met Samsung Bixby: | Nee |
| Multi-screen: | Nee |
| Afstandsbediening inbegrepen: | Ja |
| (Buitenste) hoofdverpakking hoogte: | 512 mm |
| (Buitenste) hoofdverpakking breedte: | 800 mm |
| (Buitenste) hoofdverpakking brutogewicht: | 5300 g |
| (Buitenste) hoofdverpakking lengte: | 126 mm |
| Hoeveelheid per (buitenste) hoofdverpakking: | 1 stuk(s) |
| Pallet brutogewicht: | 107900 g |
| Producten per pallet: | 18 stuk(s) |
| Wifi: | Ja |
| AC-ingangsspanning: | 220 - 240 V |
| AC-ingangsfrequentie: | 50 Hz |
| Stroomverbruik (typisch): | - W |
| Batterijen inbegrepen: | Ja |
| Werkt met de Google Assistent: | Ja |
| Slaaptimer: | Ja |
| Batterijtechnologie: | Alkaline |
| Type batterij: | AAA |
| Energie-efficiëntieschaal: | A tot G |
| Spraakbesturing: | Nee |
| Pallet brutohoogte: | 1164 mm |
| Pallet brutobreedte: | 800 mm |
| Pallet brutolengte: | 1200 mm |
| Producten per palletlaag: | 9 stuk(s) |
| Lagen per pallet: | 2 stuk(s) |
| GTIN (EAN/UPC)-nummer (buitenste) hoofdverpakking: | 5901292517120 |
| Aantal per doos: | 1 stuk(s) |
| (Buitenste) hoofdverpakking inhoud: | 51609.6 cm³ |
| Verpakkingsvolume: | 51609.6 cm³ |
| Nettogewicht pallet: | 107900 g |
| Pallet nettobreedte: | 800 mm |
| Pallet nettodiepte: | 1200 mm |
| Pallet nettohoogte: | 1164 mm |
| Far-field steminteractie: | Nee |
| Introductie jaar: | 2022 |
| Mini muurbevestigingssteun: | Nee |
| Reparatie-index: | 6.4 |
| HDMI Quick Switch: | Ja |
| Chemische belasting (Zweden): | Ja |
| Maximum aantal stapelbare verpakkingen: | 5 stuk(s) |
| Type vrachtwagen: | 87 cbm |
| Aantal per vrachtwagen: | 1188 stuk(s) |
| Aantal pallets per vrachtwagen: | 66 stuk(s) |
| Verlaging chemische belasting (Zweden): | 50 |
| One Conect-kabelondersteuning: | Nee |
| One Connect doos: | Nee |
| Ondersteunde accu's/batterijen: | 2 |
| Batterijen inbegrepen (type, aantal): | 2 |
